System And Components
418-4701 PANEL GP-CONTROL (CHG -02)OCP 4.3
Group No: 418-4701
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 10 | |
| 1036272 | 2 SEAL (CONTROL) | 1 | |
| 1152538 | 3 COVER-END | 2 | |
| 1165140 | 4 TERMINAL | 6 | |
| 1735413 | 5 CLAMP (END) | 6 | |
| 2039007 | 6 NUT (1-1/2-18-THD) | 1 | |
| 2250547 | 7 BLOCK-TERMINAL | 81 | |
| 2250548 | 8 COVER | 3 | |
| 2250906 | 9 BRIDGE (2-POSITION) | 2 | |
| 2295291 | 10 TERMINAL (DOUBLE) | 5 | |
| 2702679 | 11 LOCKWASHER | 1 | |
| 3392958 | 12 GASKET | 1 | |
| 3407298 | 13 CAP AS-PROTECTION | 1 | |
| 3503459 | 14 MODULE (ETHERNET) | 1 | |
| 3687965 | 15 CONTROL GP-GENERATOR SET (UNPROGRAMMED) | 1 | |
| 3901208 | 16 SHROUD | 1 | |
| 3901209 | 17 SWITCH AS (EMERGENCY STOP) | 1 | |
| 4336752 | 18 PANEL AS (CONTROL) | 1 | |
| 7T1099 | LINK | 2 | |
| 4336753 | 19 MARKER AS-TERMINAL | 1 | |
| 4336754 | 20 HARNESS AS-PANEL (CONTROL) | 1 | |
| 4336755 | 21 PANEL AS | 1 | |
| 7T1099 | LINK | 8 | |
| 4336756 | 22 BRACKET | 4 | |
| 4336762 | 23 BLOCK-TERMINAL | 2 | |
| 4336764 | 24 PLUG | 2 | |
| 4200437 | 25 SWITCH-PUSH (GREEN) | 1 | |
| 4484866 | 29 GASKET | 1 | |
| 4606273 | 30 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 1H3338 | 31 LOCKWASHER | 6 | |
| 4F7957 | 32 BOLT (1/4-20X0.875-IN) | 8 | |
| 5P0537 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 6V8225 | 34 NUT (M6X1-THD) | 6 | |
| 9S8750 | 35 NUT-FULL (1/4-20-THD) | 8 | |
| 9X8267 | 36 WASHER (6.6X12X2-MM THK) | 6 |
