System And Components
379-9022 LINES GP-TURBOCHARGER OIL (CHG -05, -06)
Group No: 379-9022
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3898372 | 1 HOSE AS | 1 | |
| 3943568 | 2 TUBE AS | 1 | |
| 3943569 | 3 TUBE AS | 1 | |
| 4200810 | 4 BRACKET | 2 | |
| 4854913 | 5 HOSE AS | 1 | |
| 4854908 | 6 TUBE AS | 1 | |
| 0S1587 | 7 BOLT (1/2-13X1.75-IN) | 2 | |
| 0S1588 | 8 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 1 | |
| 3537952 | 10 GROMMET | 1 | |
| 1A2029 | 11 BOLT (3/8-16X1.125-IN) | 3 | |
| 1F7958 | 12 NUT-FULL (1/2-13-THD) | 2 | |
| 2287092 | 13 SEAL-O-RING | 1 | |
| 3295528 | 14 ELBOW AS | 1 | |
| 8T8899 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 3P0649 | 15 SEAL-O-RING | 2 | |
| 6K5290 | 16 CLIP (TAB) | 1 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P5846 | 18 SEAL-O-RING | 2 | |
| 6K5291 | 19 CLIP (SLOT) | 1 | |
| 6K6165 | 20 CLIP | 1 | |
| 6K6166 | 21 BRACKET | 2 | |
| 2815972 | 22 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196216 | 23 CONNECTOR AS | 1 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3342779 | 24 CONNECTOR AS | 1 | |
| 8T0078 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3196236 | 25 TEE AS | 1 | |
| 6V9839 | TEE-SWIVEL | 1 | |
| 2287092 | SEAL-O-RING | 2 | |
| 7D1649 | 26 WASHER-HARD (13.5X32X5-MM THK) | 4 | |
| 8S0023 | 27 CLIP (SLOT) | 1 | |
| 8S0024 | 28 CLIP (TAB) | 1 | |
| 9S8752 | 29 NUT-FULL (3/8-16-THD) | 1 | |
| 9X6458 | 30 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
