Assembly
100%

379-9028 LINES GP-TURBOCHARGER WATER (CHG -07, -08)

Group No: 379-9028
Part NumberPart NameQty
14884451 TEE AS3
5K9090SEAL-O-RING2
6V9847TEE-SWIVEL1
2W37932 TUBE1
2W40323 RETAINER4
7W39334 RING-RETAINING2
7W42615 ELBOW1
7W42626 TEE1
8N03947 RETAINER4
11751708 CLIP1
35928909 PLUG AS4
1559646SEAL1
3676005PLUG1
359289110 CONNECTOR AS4
5K9090SEAL-O-RING1
1559646SEAL1
3675998CONNECTOR1
381707111 ADAPTER1
381707212 BRACKET2
441606013 BRACKET1
477603514 TUBE AS1
477603615 TUBE AS1
482836416 TUBE AS1
482836317 TUBE AS1
482836218 TUBE AS1
482836519 HOSE AS2
482836620 BRACKET2
6V894421 REDUCER2
478373622 BRACKET1
0S158823 BOLT (3/8-16X1.25-IN)4
165393124 BOLT (3/8-16X1.75-IN)4
0S159425 BOLT (3/8-16X1-IN)10
109007226 SEAL-O-RING3
091008127 SPACER (10.5X20X10-MM THK)2
153624728 CONNECTOR AS1
5K9090SEAL-O-RING1
8C6875CONNECTOR1
1D460929 BOLT (3/4-10X3-IN)2
1A202930 BOLT (3/8-16X1.125-IN)5
1D461031 BOLT (3/4-10X3.25-IN)2
1W702032 RING-RETAINING2
239503233 CONNECTOR2
3B191534 BOLT (3/8-16X1.375-IN)3
3V330835 WASHER-HARD (10.2X20.5X2.5-MM THK)13
5K909036 SEAL-O-RING3
6V855737 NUT-FACE SEAL (1-7/16-12-THD)2
5P824838 WASHER-HARD (20X36.5X3.5-MM THK)4
6K493439 CLIP (SLOT)2
6K493540 CLIP (TAB)2
6V158541 SEAL-O-RING1
6V840042 SEAL-O-RING2
9X645843 WASHER-HARD (10.2X22.5X3-MM THK)17
7K321544 BOSS (0.413X1X0.630-IN THK)1
7L658045 SEAL-O-RING2
8T188946 CLIP (SLOT)6
8T189047 CLIP (TAB)6
381950348 SPACER (10.5X25X20-MM THK)2
9S875249 NUT-FULL (3/8-16-THD)8
