System And Components
418-9058 LINES GP-WATER -JACKET WATER (CHG -06, -07)
Group No: 418-9058
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4072 | 1 RETAINER | 4 | |
| 1W4099 | 2 RING-RETAINING | 2 | |
| 7E7209 | 3 RING-RETAINING | 2 | |
| 3132506 | 4 CLAMP AS | 8 | |
| 1539964 | 5 RING | 4 | |
| 2484792 | 6 CLAMP AS | 4 | |
| 3545429 | 7 FLANGE | 2 | |
| 3678480 | 8 GROMMET | 2 | |
| 3841237 | 9 FLANGE | 3 | |
| 4189049 | 10 TUBE | 1 | |
| 4189051 | 11 TUBE AS | 1 | |
| 4981193 | 12 TUBE | 1 | |
| 4189054 | 13 TUBE | 1 | |
| 4597802 | 14 BRACKET | 1 | |
| 1653931 | 15 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1588 | 16 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1590 | 17 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 18 BOLT (3/8-16X1-IN) | 2 | |
| 0S1619 | 19 BOLT (3/8-16X3-IN) | 8 | |
| 0T0573 | 20 BOLT (3/8-16X2.75-IN) | 4 | |
| 0S1587 | 21 BOLT (1/2-13X1.75-IN) | 1 | |
| 1A2029 | 22 BOLT (3/8-16X1.125-IN) | 12 | |
| 1F7958 | 23 NUT-FULL (1/2-13-THD) | 1 | |
| 2885476 | 24 SEAL-O-RING | 4 | |
| 2W5023 | 25 GASKET | 2 | |
| 3V3308 | 26 WASHER-HARD (10.2X20.5X2.5-MM THK) | 6 | |
| 4K0367 | 27 NUT-FULL (5/8-11-THD) | 2 | |
| 7X7906 | 28 CLIP (TAB) | 2 | |
| 7X7907 | 29 CLIP (SLOT) | 2 | |
| 6V5139 | 30 SEAL-O-RING | 4 | |
| 7B3235 | 31 BOLT (1/2-13X1.375-IN) | 1 | |
| 5P8247 | 32 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 5P8245 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 0S1589 | 34 BOLT (5/8-11X1.75-IN) | 2 | |
| 8C3072 | 35 SEAL-O-RING | 3 | |
| 9S8752 | 36 NUT-FULL (3/8-16-THD) | 12 | |
| 9X6458 | 37 WASHER-HARD (10.2X22.5X3-MM THK) | 40 | |
| 4981194 | 38 BRACKET AS | 1 | |
| 1A0458 | 39 BOLT (3/4-10X1.75-IN) | 2 | |
| 5P8248 | 40 WASHER-HARD (20X36.5X3.5-MM THK) | 2 |
