System And Components
377-7387 LINES GP-AIR (CHG -09)AIR INLET CHOKE
Group No: 377-7387
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5086705 | 1 BRACKET | 1 | |
| 6I1641 | 2 PLATE | 1 | |
| 6I1642 | 3 PLATE | 1 | |
| 6I1643 | 4 COVER AS | 1 | |
| 6I1644 | 5 WASHER-THRUST | 1 | |
| 1763583 | 6 GUARD | 2 | |
| 1763587 | 7 CLEVIS | 1 | |
| 1837232 | 8 BELLOWS AS | 2 | |
| 1937879 | 9 BOOT | 1 | |
| 2118175 | 10 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC) | 1 | |
| 2274056 | 11 GASKET | 3 | |
| 2279012 | 12 GASKET | 6 | |
| 3777376 | 13 ADAPTER | 1 | |
| 3777384 | 14 ELBOW | 2 | |
| 3799012 | 15 SUPPORT AS | 1 | |
| 5500794 | 16 BRACKET | 1 | |
| 3799016 | 17 ADAPTER AS | 1 | |
| 5644798 | 18 BRACKET | 2 | |
| 3799029 | 19 BRACKET AS | 1 | |
| 3841216 | 20 SHAFT | 1 | |
| 3841217 | 21 ROD-CONTROL | 1 | |
| 4217816 | 22 BRACKET AS | 1 | |
| 4217817 | 23 BRACKET AS | 1 | |
| 4256727 | 24 PLATE-BUTTERFLY | 1 | |
| 4263488 | 25 HOUSING AS | 1 | |
| 6V5041 | SEAL-LIP TYPE | 2 | |
| 1611201 | BUSHING | 2 | |
| 4499230 | 26 BRACKET AS | 1 | |
| 0321768 | 27 SETSCREW (3/8-16-THD) | 1 | |
| 0929012 | 28 SPACER (17X32X9-MM THK) | 9 | |
| 0L2070 | 29 BOLT (3/8-16X2.25-IN) | 14 | |
| 1653931 | 30 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1585 | 31 BOLT (1/2-13X1.5-IN) | 10 | |
| 0S1589 | 32 BOLT (5/8-11X1.75-IN) | 6 | |
| 1653931 | 33 BOLT (3/8-16X1.75-IN) | 2 | |
| 1653929 | 34 BOLT (3/8-16X1.5-IN) | 8 | |
| 0S1594 | 35 BOLT (3/8-16X1-IN) | 2 | |
| 0S1625 | 36 BOLT (5/8-11X2.5-IN) | 2 | |
| 1683349 | 37 PLUG-PIPE | 1 | |
| 1A1460 | 38 BOLT (1/2-13X2-IN) | 2 | |
| 1A2029 | 39 BOLT (3/8-16X1.125-IN) | 4 | |
| 1A9579 | 40 BOLT (5/16-18X1.5-IN) | 1 | |
| 1C2251 | 41 BOLT (3/8-16X1.87-IN) | 1 | |
| 1F7958 | 42 NUT-FULL (1/2-13-THD) | 24 | |
| 1S3584 | 43 NUT-FULL (3/8-24 LH-THD) | 1 | |
| 2M0849 | 44 WASHER-HARD (13.5X25.5X5-MM THK) | 8 | |
| 3512247 | 45 BOLT (3/8-16X1.5-IN) | 4 | |
| 3S2713 | 46 NUT-FULL (3/8-24-THD) | 1 | |
| 3V3308 | 47 WASHER-HARD (10.2X20.5X2.5-MM THK) | 29 | |
| 4P0394 | 48 LEVER | 1 | |
| 5M2894 | 49 WASHER-HARD (10.2X18.5X2.5-MM THK) | 21 | |
| 5P8245 | 50 WASHER-HARD (13.5X25.5X3-MM THK) | 30 | |
| 5P8247 | 51 WASHER-HARD (17X32X3.5-MM THK) | 22 | |
| 5S0003 | 52 NUT (5/16-18-THD) | 1 | |
| 6V6845 | 53 BOLT-LOCKING (1/4-20X1.25-IN) | 4 | |
| 7D1649 | 54 WASHER-HARD (13.5X32X5-MM THK) | 16 | |
| 7X7874 | 55 ROD END | 1 | |
| 7X7875 | 56 ROD END | 1 | |
| 8B7997 | 57 BOLT-SOCKET HEAD (1/2-13X2-IN) | 2 | |
| 8H3390 | 58 NUT-FULL (1-1/2-12-THD) | 1 | |
| 8M9024 | 59 WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 8S9089 | 60 BOLT (1/2-13X4.5-IN) | 4 | |
| 9S8752 | 61 NUT-FULL (3/8-16-THD) | 17 | |
| 2B0947 | 62 BOLT (1/2-13X2.25-IN) | 14 | |
| 1A1135 | 63 BOLT (5/8-11X2-IN) | 7 | |
| 8S9092 | 64 BOLT (5/8-11X2.25-IN) | 7 | |
| 5500795 | 65 PLATE AS | 1 | |
| 5644797 | 66 BRACKET | 5 |
