System And Components
379-9024 LINES GP-AIR -BYPASS (CHG -00, -01)FOR USE WITH G3600 ENGINES
Group No: 379-9024
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9S9635 | 1 JOINT AS-TUBE | 2 | |
| 9X7523 | SEAL | 2 | |
| 3753869 | 2 GASKET | 2 | |
| 3799025 | 3 BRACKET AS | 1 | |
| 3841204 | 4 TUBE AS | 1 | |
| 3841205 | 5 TUBE AS | 1 | |
| 3841206 | 6 TUBE AS | 1 | |
| 3841214 | 7 BRACKET AS | 1 | |
| 3841242 | 8 BRACKET AS | 1 | |
| 3914979 | 9 BRACKET AS | 1 | |
| 3943557 | 10 BRACKET | 1 | |
| 3943575 | 11 TUBE AS | 1 | |
| 1653931 | 12 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 8 | |
| 0S1589 | 14 BOLT (5/8-11X1.75-IN) | 8 | |
| 0S1590 | 15 BOLT (3/8-16X2-IN) | 4 | |
| 1653929 | 16 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 2 | |
| 1058180 | 18 GASKET | 3 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 2 | |
| 3B1915 | 20 BOLT (3/8-16X1.375-IN) | 4 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 28 | |
| 5P8247 | 22 WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 6V1581 | 23 CLIP (SLOT) | 1 | |
| 6V1582 | 24 CLIP (TAB) | 1 | |
| 9S8752 | 25 NUT-FULL (3/8-16-THD) | 14 | |
| 9X6458 | 26 WASHER-HARD (10.2X22.5X3-MM THK) | 10 |
