System And Components
386-2044 CONTROL GP-ENGINE ELECTRONIC (CHG -01)
Group No: 386-2044
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I1418 | 1 SPACER (8.2X12.7X28.7-MM THK) | 10 | |
| 8T9655 | 2 MOUNT-ISOLATION | 16 | |
| 1270594 | 3 WIRE AS-GROUND | 1 | |
| 1314891 | 4 GASKET | 6 | |
| 1328489 | 5 NUT-RING | 6 | |
| 1878674 | 6 BLOCK AS-JUNCTION | 2 | |
| 1878675 | 7 GASKET | 3 | |
| 2039007 | 8 NUT (1-1/2-18-THD) | 1 | |
| 2059470 | 9 MOUNT-FLEXIBLE | 6 | |
| 2345925 | 10 GASKET | 1 | |
| 2702679 | 11 LOCKWASHER | 1 | |
| 3089773 | 12 SWITCH AS-PUSH BUTTON (RED) | 1 | |
| 3089774 | 13 RING | 1 | |
| 3089775 | 14 LATCH-MOUNTING | 1 | |
| 3089777 | 15 BLOCK-CONTACT | 2 | |
| 3203063 | 16 SENSOR GP-PRESSURE (AMBIENT) | 1 | |
| 3238737 | 17 CONTROL GP-UNPROGRAMMED (ELECTRONIC)(ELECTRONIC) | 1 | |
| 3247659 | 18 BLOCK AS-JUNCTION | 1 | |
| 3247885 | 19 NUT-RING | 16 | |
| 3392958 | 20 GASKET | 1 | |
| 3407298 | 21 CAP AS-PROTECTION | 1 | |
| 3538089 | 22 CONTROL GP-UNPROGRAMMED (ISM) | 1 | |
| 3555886 | 23 RECEPTACLE AS | 1 | |
| 1490231 | SEAL-O-RING | 1 | |
| 3601816 | NUT | 1 | |
| 3862012 | 24 BRACKET AS | 1 | |
| 7T1099 | LINK | 2 | |
| 3862013 | 25 WIRING GP-ENGINE (ELECTRONIC) | 1 | |
| 3862045 | 26 BOX GP-JUNCTION (ENGINE) | 1 | |
| 3862054 | 27 ADAPTER AS | 2 | |
| 3H5366 | STUD-WELD (1/4-20X0.625-IN) | 6 | |
| 3862055 | 28 GASKET | 2 | |
| 0S1614 | 29 BOLT (1/4-20X0.5-IN) | 3 | |
| 0T0102 | 30 BOLT (3/8-16X0.625-IN) | 4 | |
| 1B9575 | 31 BOLT (5/16-18X1.56-IN) | 2 | |
| 2442331 | 32 WASHER (4X8X1-MM THK) | 64 | |
| 2P1279 | 33 LOCKNUT (9/16-18-THD) | 1 | |
| 3353999 | 34 CONNECTOR | 1 | |
| 3J1907 | 35 SEAL-O-RING | 3 | |
| 3S2093 | 36 STRAP-CABLE | 10 | |
| 4B2047 | 37 NUT (10-24-THD) | 12 | |
| 4B3903 | 38 BOLT (5/16-18X4-IN) | 2 | |
| 4B5324 | 39 WASHER (3.9X9.6X1.2-MM THK) | 24 | |
| 4P8134 | 40 CLIP (LADDER) | 5 | |
| 5M2894 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P0537 | 42 WASHER-HARD (7.2X14.5X2-MM THK) | 17 | |
| 6F9005 | 43 NUT-JAM (1/2-13-THD) | 3 | |
| 6V1051 | 44 SCREW-BUTTON HEAD (10-24X19.05-MM) | 12 | |
| 6V5683 | 45 BOLT (M6X1X16-MM) | 4 | |
| 6V8076 | 46 ELBOW | 1 | |
| 6V9028 | 47 SEAL-O-RING | 1 | |
| 7F0560 | 48 WASHER (0.516X0.938X0.101-IN THK) | 3 | |
| 7X7945 | 49 ADAPTER (9/16-18-THD) | 1 | |
| 8C8560 | 50 SCREW-LOCK (4-40X0.5-IN) | 64 | |
| 8T0328 | 51 WASHER-HARD (5.5X10X1-MM THK) | 24 | |
| 8T8911 | 52 BOLT (5/16-18X2-IN) | 2 | |
| 9N0869 | 53 WASHER-HARD (8.8X25.5X2-MM THK) | 12 | |
| 9S8750 | 54 NUT-FULL (1/4-20-THD) | 14 | |
| 9X6258 | 55 SCREW-MACHINE (6-32X0.5-IN) | 24 |
