System And Components
386-2044 CONTROL GP-ENGINE ELECTRONIC (CHG -02)
Group No: 386-2044
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W6090 | 1 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 6I1418 | 2 SPACER (8.2X12.7X28.7-MM THK) | 10 | |
| 8T9655 | 3 MOUNT-ISOLATION | 16 | |
| 1735413 | 4 CLAMP | 2 | |
| 1057543 | 5 BLOCK-FUSE | 6 | |
| 1270594 | 6 WIRE AS-GROUND | 1 | |
| 1314891 | 7 GASKET | 6 | |
| 1328489 | 8 NUT-RING | 6 | |
| 1524807 | 9 GASKET | 16 | |
| 1878674 | 10 BLOCK AS-JUNCTION | 2 | |
| 1878675 | 11 GASKET | 3 | |
| 2039007 | 12 NUT (1-1/2-18-THD) | 1 | |
| 2045593 | 13 RELAY (24-VOLT)(FUEL) | 1 | |
| 2045593 | 13A RELAY (24-VOLT)(COMPRESSOR BYPASS) | 1 | |
| 2059470 | 14 MOUNT-FLEXIBLE | 6 | |
| 2345925 | 15 GASKET | 1 | |
| 2519507 | 16 TERMINAL | 7 | |
| 2638768 | 17 COVER | 2 | |
| 2702679 | 18 LOCKWASHER | 1 | |
| 2932033 | 19 SCREW-LOCK (4-40X0.5-IN) | 64 | |
| 3089773 | 20 SWITCH AS-PUSH BUTTON (RED) | 1 | |
| 3089774 | 21 RING | 1 | |
| 3089775 | 22 LATCH-MOUNTING | 1 | |
| 3089777 | 23 BLOCK-CONTACT | 2 | |
| 3203063 | 24 SENSOR GP-PRESSURE (AMBIENT) | 1 | |
| 3238737 | 25 CONTROL GP-UNPROGRAMMED (ELECTRONIC)(ELECTRONIC) | 1 | |
| 3247659 | 26 BLOCK AS-JUNCTION | 1 | |
| 3247885 | 27 NUT-RING | 16 | |
| 3392958 | 28 GASKET | 1 | |
| 3407298 | 29 CAP AS-PROTECTION | 1 | |
| 3538088 | 30 CONTROL GP-UNPROGRAMMED (ISM) | 1 | |
| 3862012 | 31 BRACKET AS | 1 | |
| 7T1099 | LINK | 2 | |
| 3862013 | 32 WIRING GP-ENGINE (ELECTRONIC) | 1 | |
| 3862014 | 33 RAIL AS | 1 | |
| 3862045 | 34 BOX GP-JUNCTION (ENGINE) | 1 | |
| 3862054 | 35 ADAPTER AS | 2 | |
| 3H5366 | STUD-WELD (1/4-20X0.625-IN) | 6 | |
| 3862055 | 36 GASKET | 2 | |
| 4336749 | 37 MARKER-TERMINAL | 1 | |
| 4336751 | 38 STRIP-CONTACT | 2 | |
| 4443372 | 39 SEAL-WASHER | 1 | |
| 0365774 | 40 FUSE (15-AMPERE) | 3 | |
| 0S1614 | 41 BOLT (1/4-20X0.5-IN) | 3 | |
| 0T0102 | 42 BOLT (3/8-16X0.625-IN) | 4 | |
| 1B9575 | 43 BOLT (5/16-18X1.56-IN) | 2 | |
| 2147568 | 44 SEAL-O-RING | 1 | |
| 2442331 | 45 WASHER (4X8X1-MM THK) | 64 | |
| 2P1279 | 46 LOCKNUT (9/16-18-THD) | 1 | |
| 3353999 | 47 CONNECTOR | 1 | |
| 3J1907 | 48 SEAL-O-RING | 2 | |
| 3S2093 | 49 STRAP-CABLE | 10 | |
| 4B2047 | 50 NUT (10-24-THD) | 12 | |
| 4B3903 | 51 BOLT (5/16-18X4-IN) | 2 | |
| 4B5324 | 52 WASHER (3.9X9.6X1.2-MM THK) | 24 | |
| 4P8134 | 53 CLIP (LADDER) | 5 | |
| 5M2894 | 54 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P0537 | 55 WASHER-HARD (7.2X14.5X2-MM THK) | 17 | |
| 6F9005 | 56 NUT-JAM (1/2-13-THD) | 3 | |
| 6V1051 | 57 SCREW-BUTTON HEAD (10-24X19.05-MM) | 12 | |
| 6V5683 | 58 BOLT (M6X1X16-MM) | 4 | |
| 6V8076 | 59 ELBOW | 1 | |
| 6V9028 | 60 SEAL-O-RING | 1 | |
| 7F0560 | 61 WASHER (0.516X0.938X0.101-IN THK) | 3 | |
| 7X7945 | 62 ADAPTER (9/16-18-THD) | 1 | |
| 8T0328 | 63 WASHER-HARD (5.5X10X1-MM THK) | 24 | |
| 8T8911 | 64 BOLT (5/16-18X2-IN) | 2 | |
| 9N0869 | 65 WASHER-HARD (8.8X25.5X2-MM THK) | 12 | |
| 9S8750 | 66 NUT-FULL (1/4-20-THD) | 14 | |
| 9X6258 | 67 SCREW-MACHINE (6-32X0.5-IN) | 24 | |
| 9Y6027 | 68 FUSE-CERAMIC (10-AMPERE) | 3 |
