System And Components
386-1986 WIRING GP-ENGINE (CHG -02 THRU -07)PART OF 383-1792 MODIFICATION AR-ENGINE
Group No: 386-1986
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4956354 | 1 COVER AS | 16 | |
| 7K1181 | 2 STRAP-CABLE | 2 | |
| 9X6772 | 3 STRAP-CABLE | 8 | |
| 9X7688 | 4 SEAL-O-RING | 16 | |
| 1663796 | 5 TUBE AS | 16 | |
| 2434291 | 6 PLUG AS-SPARK | 16 | |
| 3248782 | 7 SEAL | 16 | |
| 3579030 | 8 CLAMP | 6 | |
| 4184696 | 10 WIRING GP-ENGINE (LH) | 1 | |
| 4184698 | 11 WIRING GP-ENGINE (RH) | 1 | |
| 4385682 | 12 TRANSFORMER GP-IGNITION (WIRING) | 16 | |
| 4394986 | 13 BRACKET AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 2 | |
| 1653929 | 14 BOLT (3/8-16X1.5-IN) | 17 | |
| 0S1585 | 15 BOLT (1/2-13X1.5-IN) | 5 | |
| 0S1615 | 16 BOLT (1/4-20X0.75-IN) | 1 | |
| 0S1617 | 17 BOLT (5/16-18X0.75-IN) | 8 | |
| 3523969 | 18 CLIP (LADDER) | 6 | |
| 3E4352 | 19 WASHER-HARD (8.8X20.5X2.5-MM THK) | 8 | |
| 3V3308 | 20 WASHER-HARD (10.2X20.5X2.5-MM THK) | 17 | |
| 4B3388 | 21 BOLT (5/16-18X1.125-IN) | 64 | |
| 5P0537 | 22 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 5P8245 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 6V3260 | 24 BOLT-SOCKET HEAD (1/4-20X0.75-IN) | 6 | |
| 6V3830 | 25 SEAL-O-RING | 16 | |
| 6V3834 | 26 SEAL-O-RING | 16 | |
| 7D1649 | 27 WASHER-HARD (13.5X32X5-MM THK) | 5 | |
| 9M1974 | 28 WASHER-HARD (8.8X16X2-MM THK) | 64 | |
| 9X8267 | 29 WASHER (6.6X12X2-MM THK) | 6 | |
| 9U5058 | KIT-REFILL | 1 |
