System And Components
443-3058 WIRING GP-ENGINE (CHG -00)
Group No: 443-3058
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N0402 | 1 BOLT-SOCKET HEAD (10-24X1.75-IN) | 12 | |
| 6S9150 | 2 CLAMP (TAB) | 1 | |
| 6S9151 | 3 CLAMP (SLOT) | 1 | |
| 9X3495 | 4 CLIP AS | 1 | |
| 0910081 | 5 SPACER (10.5X20X10-MM THK) | 2 | |
| 3579026 | 6 CLAMP | 3 | |
| 3579029 | 7 CLAMP | 1 | |
| 3579031 | 8 CLAMP | 7 | |
| 3579033 | 9 CLAMP | 6 | |
| 3586955 | 10 BRACKET AS | 2 | |
| 3596007 | 11 BRACKET AS | 3 | |
| 3596010 | 12 BRACKET AS | 1 | |
| 3609581 | 13 BRACKET AS | 2 | |
| 3623166 | 14 BRACKET AS | 1 | |
| 3722936 | 15 BRACKET AS | 1 | |
| 3724756 | 16 BRACKET | 3 | |
| 3724757 | 17 BRACKET AS | 1 | |
| 3774629 | 18 BRACKET AS | 2 | |
| 3841242 | 19 BRACKET AS | 1 | |
| 3862010 | 20 HARNESS GP-WIRING (SENSOR) | 1 | |
| 3862023 | 21 BRACKET AS | 1 | |
| 3862024 | 22 HARNESS AS-ENGINE (FRONT) | 1 | |
| 3862026 | 23 HARNESS AS-ENGINE (FUEL) | 1 | |
| 3862033 | 24 BRACKET | 1 | |
| 3862034 | 25 HARNESS AS-ENGINE (CENTER) | 1 | |
| 3943557 | 26 BRACKET | 1 | |
| 4184709 | 27 BRACKET AS | 1 | |
| 4184710 | 28 BRACKET | 1 | |
| 4433057 | 29 HARNESS AS-ENGINE (ACTUATOR) | 1 | |
| 4433059 | 30 HARNESS AS-ENGINE (TURBOCHARGER)(TURBOCHARGER) | 1 | |
| 4433061 | 31 BRACKET AS | 1 | |
| 4433062 | 32 BRACKET | 1 | |
| 0323237 | 33 SPACER (10.93X19.05X25.4-MM THK) | 1 | |
| 0L1143 | 34 BOLT (3/8-16X2.5-IN) | 1 | |
| 1653931 | 35 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1585 | 36 BOLT (1/2-13X1.5-IN) | 3 | |
| 0S1588 | 37 BOLT (3/8-16X1.25-IN) | 4 | |
| 1653929 | 38 BOLT (3/8-16X1.5-IN) | 3 | |
| 0S1594 | 39 BOLT (3/8-16X1-IN) | 11 | |
| 0S1618 | 40 BOLT (5/16-18X1-IN) | 2 | |
| 1325789 | 41 CLIP (LADDER) | 2 | |
| 1A2029 | 42 BOLT (3/8-16X1.125-IN) | 2 | |
| 1F7958 | 43 NUT-FULL (1/2-13-THD) | 4 | |
| 2H0191 | 44 BOLT (10-24X0.625-IN) | 6 | |
| 3B1915 | 45 BOLT (3/8-16X1.375-IN) | 1 | |
| 4B2047 | 46 NUT (10-24-THD) | 2 | |
| 4D9517 | 47 CLIP | 1 | |
| 4F7957 | 48 BOLT (1/4-20X0.875-IN) | 1 | |
| 4P7581 | 49 CLIP (LADDER) | 1 | |
| 4S1962 | 50 CLIP (LOOP) | 2 | |
| 5J1714 | 51 BOLT (10-24X1.5-IN) | 22 | |
| 5L9018 | 52 BOLT-SOCKET HEAD (1/4-20X1.75-IN) | 4 | |
| 5M2894 | 53 WASHER-HARD (10.2X18.5X2.5-MM THK) | 33 | |
| 5P0537 | 54 WASHER-HARD (7.2X14.5X2-MM THK) | 7 | |
| 5P8245 | 55 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 6K6165 | 56 CLIP | 2 | |
| 6K6166 | 57 BRACKET | 2 | |
| 6V4356 | 58 CLIP (SLOT) | 1 | |
| 6V4357 | 59 CLIP (TAB) | 1 | |
| 6V7697 | 60 SCREW-MACHINE (8-32X1.25-IN) | 2 | |
| 7B2742 | 61 BOLT (1/4-20X1.25-IN) | 1 | |
| 7B3235 | 62 BOLT (1/2-13X1.375-IN) | 1 | |
| 7K1181 | 63 STRAP-CABLE | 3 | |
| 7L0688 | 64 BOLT-SOCKET HEAD (10-24X1.2-IN) | 4 | |
| 8H3128 | 65 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 11 | |
| 8T0328 | 66 WASHER-HARD (5.5X10X1-MM THK) | 40 | |
| 9D6196 | 67 CLIP (SLOT) | 1 | |
| 9D6197 | 68 CLIP (TAB) | 1 | |
| 9M1974 | 69 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8750 | 70 NUT-FULL (1/4-20-THD) | 1 | |
| 9S8752 | 71 NUT-FULL (3/8-16-THD) | 9 | |
| 9X8267 | 72 WASHER (6.6X12X2-MM THK) | 3 |
