System And Components
515-5519 WIRING GP-ENGINE (CHG -00, -01)PART OF 383-1792 MODIFICATION AR-ENGINE
Group No: 515-5519
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 9X6772 | 2 STRAP-CABLE | 16 | |
| 9X7688 | 3 SEAL-O-RING | 16 | |
| 1663796 | 4 TUBE AS | 16 | |
| 2434291 | 5 PLUG AS-SPARK | 16 | |
| 3248782 | 6 SEAL | 16 | |
| 3579030 | 7 CLAMP | 6 | |
| 3774634 | 8 BRACKET AS | 2 | |
| 9D6621 | NUT-WELD (10-24-THD) | 2 | |
| 4394986 | 9 BRACKET AS | 1 | |
| 4956354 | 10 COVER AS | 16 | |
| 5126201 | 11 TRANSFORMER GP (ENGINE) | 16 | |
| 3081380 | EXTENSION AS | 1 | |
| 1873875 | SEAL-O-RING | 1 | |
| 4518550 | SEAL-O-RING | 1 | |
| 5155517 | 12 HARNESS AS-POWER (RH)(RH) | 1 | |
| 5155518 | 13 HARNESS AS-POWER (LH)(LH) | 1 | |
| 0S1585 | 14 BOLT (1/2-13X1.5-IN) | 1 | |
| 1653929 | 15 BOLT (3/8-16X1.5-IN) | 17 | |
| 0S1615 | 16 BOLT (1/4-20X0.75-IN) | 1 | |
| 1325789 | 17 CLIP (LADDER) | 2 | |
| 1A2029 | 18 BOLT (3/8-16X1.125-IN) | 1 | |
| 2N0402 | 19 BOLT-SOCKET HEAD (10-24X1.75-IN) | 24 | |
| 3V3308 | 20 WASHER-HARD (10.2X20.5X2.5-MM THK) | 17 | |
| 4B3388 | 21 BOLT (5/16-18X1.125-IN) | 64 | |
| 4P7429 | 22 CLIP (LADDER) | 2 | |
| 4P7581 | 23 CLIP (LADDER) | 1 | |
| 4P8134 | 24 CLIP (LADDER) | 11 | |
| 5J1714 | 25 BOLT (10-24X1.5-IN) | 4 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P0537 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 5P8245 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V3260 | 29 BOLT-SOCKET HEAD (1/4-20X0.75-IN) | 6 | |
| 6V3830 | 30 SEAL-O-RING | 16 | |
| 6V3834 | 31 SEAL-O-RING | 16 | |
| 7D1649 | 32 WASHER-HARD (13.5X32X5-MM THK) | 1 | |
| 8T0328 | 33 WASHER-HARD (5.5X10X1-MM THK) | 28 | |
| 9M1974 | 34 WASHER-HARD (8.8X16X2-MM THK) | 64 | |
| 9S8752 | 35 NUT-FULL (3/8-16-THD) | 1 |
