System And Components
386-2008 WIRING GP-SENSOR (CHG -01, -01D1)
Group No: 386-2008
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N0402 | 1 BOLT-SOCKET HEAD (10-24X1.75-IN) | 12 | |
| 6S9150 | 2 CLAMP (TAB) | 1 | |
| 6S9151 | 3 CLAMP (SLOT) | 1 | |
| 9X3495 | 4 CLIP AS | 1 | |
| 3579026 | 5 CLAMP | 2 | |
| 3579029 | 6 CLAMP | 1 | |
| 3579031 | 7 CLAMP | 4 | |
| 3579033 | 8 CLAMP | 5 | |
| 3596007 | 9 BRACKET AS | 2 | |
| 3596010 | 10 BRACKET AS | 1 | |
| 3609581 | 11 BRACKET AS | 1 | |
| 3623166 | 12 BRACKET AS | 1 | |
| 3722936 | 13 BRACKET AS | 1 | |
| 3724756 | 14 BRACKET | 1 | |
| 3724757 | 15 BRACKET AS | 2 | |
| 3862010 | 16 HARNESS GP-WIRING (SENSOR) | 1 | |
| 3862023 | 17 BRACKET AS | 1 | |
| 3862024 | 18 HARNESS AS-ENGINE (FRONT) | 1 | |
| 3862026 | 19 HARNESS AS-ENGINE (FUEL) | 1 | |
| 3862028 | 20 HARNESS AS-ENGINE (ACTUATOR) | 1 | |
| 3862031 | 21 HARNESS AS-ENGINE (TURBO) | 1 | |
| 3862033 | 22 BRACKET | 1 | |
| 3862034 | 23 HARNESS AS-ENGINE (CENTER) | 1 | |
| 4184688 | 24 BRACKET AS | 1 | |
| 4184709 | 25 BRACKET AS | 1 | |
| 4184710 | 26 BRACKET | 1 | |
| 9X6380 | 27 BOLT (5/8-11X1.5-IN) | 1 | |
| 1653931 | 28 BOLT (3/8-16X1.75-IN) | 5 | |
| 0S1585 | 29 BOLT (1/2-13X1.5-IN) | 1 | |
| 0S1587 | 30 BOLT (1/2-13X1.75-IN) | 1 | |
| 0S1588 | 31 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 32 BOLT (3/8-16X1-IN) | 3 | |
| 0S1618 | 33 BOLT (5/16-18X1-IN) | 2 | |
| 1F7958 | 34 NUT-FULL (1/2-13-THD) | 2 | |
| 2H0191 | 35 BOLT (10-24X0.625-IN) | 5 | |
| 3B1915 | 36 BOLT (3/8-16X1.375-IN) | 1 | |
| 4B2047 | 37 NUT (10-24-THD) | 2 | |
| 4D9517 | 38 CLIP | 1 | |
| 4F7957 | 39 BOLT (1/4-20X0.875-IN) | 1 | |
| 4K0367 | 40 NUT-FULL (5/8-11-THD) | 1 | |
| 5J1714 | 41 BOLT (10-24X1.5-IN) | 18 | |
| 5L9018 | 42 BOLT-SOCKET HEAD (1/4-20X1.75-IN) | 6 | |
| 5M2894 | 43 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 5P0537 | 44 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 5P8245 | 45 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P8247 | 46 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 6V4356 | 47 CLIP (SLOT) | 1 | |
| 6V4357 | 48 CLIP (TAB) | 1 | |
| 6V7697 | 49 SCREW-MACHINE (8-32X1.25-IN) | 6 | |
| 7B2742 | 50 BOLT (1/4-20X1.25-IN) | 1 | |
| 7L0688 | 51 BOLT-SOCKET HEAD (10-24X1.2-IN) | 6 | |
| 8H3128 | 52 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 7 | |
| 8T0328 | 53 WASHER-HARD (5.5X10X1-MM THK) | 38 | |
| 8T1593 | 54 CLIP | 1 | |
| 9D6196 | 55 CLIP (SLOT) | 1 | |
| 9D6197 | 56 CLIP (TAB) | 1 | |
| 9M1974 | 57 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S8750 | 58 NUT-FULL (1/4-20-THD) | 1 | |
| 9S8752 | 59 NUT-FULL (3/8-16-THD) | 5 | |
| 9X8267 | 60 WASHER (6.6X12X2-MM THK) | 3 |
