System And Components
379-9020 BYPASS GP-EXHAUST (CHG -00 THRU -09)
Group No: 379-9020
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4F2753 | 1 LOCKNUT | 1 | |
| 5695324 | 2 PLATE | 1 | |
| 1023457 | 3 COVER | 1 | |
| 1026309 | 4 WASHER-THRUST | 1 | |
| 1026311 | 5 STOP | 1 | |
| 1195931 | 6 SPACER | 1 | |
| 1338501 | 7 COVER AS | 1 | |
| 1763583 | 8 GUARD | 2 | |
| 1763587 | 9 CLEVIS | 1 | |
| 1937879 | 10 BOOT | 1 | |
| 2118175 | 11 ACTUATOR GP-ELECTRONIC (ELECTROHYDRAULIC) | 1 | |
| 2224718 | 12 BELLOWS AS | 2 | |
| 5836760 | 13 SHAFT-WASTEGATE | 1 | |
| 4164960 | 14 TEE AS | 1 | |
| 1195929 | 14A BUSHING | 2 | |
| 4470674 | 15 LINK AS | 1 | |
| 1S3584 | NUT-FULL (3/8-24 LH-THD) | 1 | |
| 1987370 | NUT (3/8-24-THD) | 1 | |
| 1653931 | 16 BOLT (3/8-16X1.75-IN) | 2 | |
| 1108314 | 17 WASHER (10.3X18.3X2.66-MM THK) | 64 | |
| 1C2251 | 18 BOLT (3/8-16X1.87-IN) | 1 | |
| 2N2766 | 19 LOCKNUT (3/8-16-THD) | 30 | |
| 3512247 | 20 BOLT (3/8-16X1.5-IN) | 4 | |
| 4P0394 | 21 LEVER | 1 | |
| 5H2532 | 22 KEY-WOODRUFF | 1 | |
| 5M2894 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5P7128 | 24 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 30 | |
| 5P9960 | 25 BOLT (1/4-20X0.75-IN) | 2 | |
| 6V1943 | 26 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN) | 3 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 3 | |
| 7E0701 | 28 GASKET | 5 | |
| 8H3390 | 29 NUT-FULL (1-1/2-12-THD) | 1 | |
| 8M2295 | 30 BOLT (3/8-16X1.625-IN) | 2 |
