439-4974 WIRING GP-ENGINE (CHG -00, -01)

Group No: 439-4974
Part NumberPart NameQty
2N04021 BOLT-SOCKET HEAD (10-24X1.75-IN)2
6S91502 CLAMP (TAB)1
6S91513 CLAMP (SLOT)1
7K11814 STRAP-CABLE5
35790265 CLAMP2
35790306 CLAMP2
35790317 CLAMP3
37229338 BRACKET AS1
38412429 BRACKET AS1
439497910 HARNESS AS-SENSOR (ACTUATOR)1
443306211 BRACKET1
456374812 HARNESS GP-WIRING (FRONT)1
456374913 HARNESS GP-WIRING (FUEL)1
456375014 HARNESS GP-WIRING (TURBOCHARGER)1
456375115 HARNESS GP-WIRING (CENTER)1
456375216 HARNESS GP-WIRING (RAIL)1
032323717 SPACER (10.93X19.05X25.4-MM THK)2
091008118 SPACER (10.5X20X10-MM THK)5
0L114319 BOLT (3/8-16X2.5-IN)1
165393120 BOLT (3/8-16X1.75-IN)4
0S158521 BOLT (1/2-13X1.5-IN)2
0S158822 BOLT (3/8-16X1.25-IN)10
165392923 BOLT (3/8-16X1.5-IN)2
0S159424 BOLT (3/8-16X1-IN)11
0S159525 BOLT (1/2-13X1.25-IN)1
0S161826 BOLT (5/16-18X1-IN)2
0S161927 BOLT (3/8-16X3-IN)1
132578928 CLIP (LADDER)3
1A202929 BOLT (3/8-16X1.125-IN)2
1F795830 NUT-FULL (1/2-13-THD)4
3B191531 BOLT (3/8-16X1.375-IN)1
4D951732 CLIP2
4F795733 BOLT (1/4-20X0.875-IN)1
4P758134 CLIP (LADDER)1
4P813435 CLIP (LADDER)1
4S196236 CLIP (LOOP)2
4S445537 CLIP1
5J171438 BOLT (10-24X1.5-IN)4
5L901839 BOLT-SOCKET HEAD (1/4-20X1.75-IN)4
5M289440 WASHER-HARD (10.2X18.5X2.5-MM THK)40
5P053741 WASHER-HARD (7.2X14.5X2-MM THK)5
5P824542 WASHER-HARD (13.5X25.5X3-MM THK)8
6K616543 CLIP2
6K616644 BRACKET2
6V337845 CLIP1
6V435646 CLIP (SLOT)1
6V435747 CLIP (TAB)1
6V769748 SCREW-MACHINE (8-32X1.25-IN)2
7B323549 BOLT (1/2-13X1.375-IN)1
8H312750 BOLT (1/4-20X0.75-IN)2
8H312851 BOLT-SOCKET HEAD (1/4-20X0.625-IN)5
8J341552 GROMMET1
8M277053 CLIP (LOOP)1
8T032854 WASHER-HARD (5.5X10X1-MM THK)6
9M197455 WASHER-HARD (8.8X16X2-MM THK)2
9S875256 NUT-FULL (3/8-16-THD)8
9X645857 WASHER-HARD (10.2X22.5X3-MM THK)1
9X826758 WASHER (6.6X12X2-MM THK)2
