System And Components
516-6847 WIRING GP-ENGINE (CHG -00)
Group No: 516-6847
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6772 | 1 STRAP-CABLE | 12 | |
| 9X7688 | 2 SEAL-O-RING | 12 | |
| 1663796 | 3 TUBE AS | 12 | |
| 2434291 | 4 SPARK PLUG | 12 | |
| 9Y6792 | GASKET-SPARK PLUG | 1 | |
| 3579030 | 6 CLAMP | 7 | |
| 5126201 | 7 TRANSFORMER GP (ENGINE) | 12 | |
| 3248782 | 8 SEAL | 12 | |
| 3774634 | 9 BRACKET AS | 2 | |
| 9D6621 | NUT-WELD (10-24-THD) | 2 | |
| 4394986 | 10 BRACKET AS | 1 | |
| 4956354 | 11 COVER AS | 12 | |
| 9U5058 | KIT-REFILL | 1 | |
| 1653929 | 12 BOLT (3/8-16X1.5-IN) | 13 | |
| 0S1615 | 13 BOLT (1/4-20X0.75-IN) | 1 | |
| 5166845 | 14 HARNESS AS-POWER (RH) | 1 | |
| 5166846 | 15 HARNESS AS-POWER (LH) | 1 | |
| 0S1585 | 16 BOLT (1/2-13X1.5-IN) | 1 | |
| 3V3308 | 17 WASHER-HARD (10.2X20.5X2.5-MM THK) | 13 | |
| 4B3388 | 18 BOLT (5/16-18X1.125-IN) | 48 | |
| 5P0537 | 19 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 6V3260 | 20 BOLT-SOCKET HEAD (1/4-20X0.75-IN) | 7 | |
| 6V3830 | 21 SEAL-O-RING | 12 | |
| 6V3834 | 22 SEAL-O-RING | 12 | |
| 9M1974 | 23 WASHER-HARD (8.8X16X2-MM THK) | 48 | |
| 9X8267 | 24 WASHER (6.6X12X2-MM THK) | 7 | |
| 1325789 | 25 CLIP (LADDER) | 2 | |
| 1A2029 | 26 BOLT (3/8-16X1.125-IN) | 1 | |
| 2N0402 | 27 BOLT-SOCKET HEAD (10-24X1.75-IN) | 16 | |
| 4P7429 | 28 CLIP | 2 | |
| 4P7581 | 29 CLIP (LADDER) | 1 | |
| 4P8134 | 30 CLIP (LADDER) | 7 | |
| 5J1714 | 31 BOLT (10-24X1.5-IN) | 4 | |
| 5M2894 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 7D1649 | 34 WASHER-HARD (13.5X32X5-MM THK) | 1 | |
| 8T0328 | 35 WASHER-HARD (5.5X10X1-MM THK) | 20 | |
| 9S8752 | 36 NUT-FULL (3/8-16-THD) | 1 |
