System And Components
425-3722 INTERFACE & MOUNTING GP -AUTOMATIONPART OF 419-8416 PANEL GP-ELECTRICAL
Group No: 425-3722
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2235994 | 1 WASHER-SPRING | 8 | |
| 3290570 | 2 RELAY | 3 | |
| 1635833 | 3 RELAY (24-VOLT) | 6 | |
| 2584178 | 6 FLANGE-MOUNTING | 1 | |
| 3386733 | 7 TERMINAL | 14 | |
| 3187723 | 8 RAIL (1-M) | ||
| 3187724 | 9 DUCT (1-M) | ||
| 3187725 | 10 DUCT (1-M) | ||
| 4346708 | 11 MOUNT | 4 | |
| 3055121 | 12 CLAMP | 2 | |
| 3462579 | 13 CONTROLLER AS | 1 | |
| 1690705 | SEAL | 12 | |
| 2538111 | PLUG (12-PIN) | 1 | |
| 2538113 | WEDGE (12-PIN) | 1 | |
| 2878955 | 14 NUT (M5X0.8-THD) | 6 | |
| 1305300 | 18 CLIP | 4 | |
| 2235993 | 19 WASHER (6X12X1-MM THK) | 14 | |
| 2306375 | 21 BOLT (M5X0.8X12-MM) | 2 | |
| 2306376 | 22 WASHER-SPECIAL | 32 | |
| 3162770 | 23 WASHER (3X6X0.8-MM THK) | 13 | |
| 3214476 | 24 RELAY | 1 | |
| 3214503 | 25 COVER | 4 | |
| 4322183 | 29 RELAY | 2 | |
| 8T8442 | 30 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 2088469 | 31 LOCKNUT (M6X1-THD) | 4 | |
| 4368712 | 32 SPACER (6.3X10X2.5-MM THK) | 4 | |
| 9X8267 | 33 WASHER (6.6X12X2-MM THK) | 4 |
