System And Components
307-1130 PANEL GP-ELECTRICAL -BARRIER CONTROLFOR USE WITH AREA ISOLATION SYSTEM
Group No: 307-1130
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2503557 | 1 SCREW (M5X0.8X12-MM) | 12 | |
| 3214532 | 2 SEAL | 1 | |
| 3241840 | 3 MODULE | 1 | |
| 1S9593 | 4 STRAP-CABLE | 22 | |
| 1005805 | 5 CAP-RECEPTACLE (3-PIN) | 1 | |
| 3386733 | 6 TERMINAL | 7 | |
| 2038944 | 7 GASKET | 1 | |
| 2459167 | 8 NUT (M4X0.7X5.5-MM) | 8 | |
| 3033844 | 9 ISOLATOR | 1 | |
| 9X4405 | 10 CAP-RECEPTACLE | 1 | |
| 3033859 | 11 COVER-BOX | 1 | |
| 3033860 | 12 BRACKET | 4 | |
| 3033861 | 13 LATCH | 1 | |
| 3053884 | 14 SCREW (M3X10X10-MM) | 20 | |
| 3053890 | 15 SCREW (M4X12X10-MM) | 8 | |
| 3055121 | 16 CLAMP | 11 | |
| 3055122 | 17 TERMINAL | 4 | |
| 3055127 | 18 GASKET | 4 | |
| 3055128 | 19 TERMINAL | 12 | |
| 3132865 | 20 TERMINAL | 3 | |
| 3132867 | 21 TERMINAL | 6 | |
| 3162769 | 22 NUT (M3X0.5-THD) | 20 | |
| 3162770 | 23 WASHER (3X6X0.8-MM THK) | 20 | |
| 3187612 | 24 MODULE (TERMINAL, ELECTRONIC MODULE) | 2 | |
| 3187613 | 25 MODULE (TERMINAL, POWER MODULE) | 1 | |
| 3241944 | 26 CABLE AS | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 3214528 | 27 RELAY (24-VDC) | 2 | |
| 3214420 | 28 CONVERTER | 1 | |
| 3214465 | 29 SWITCH-PUSH BUTTON (SHUTDOWN RESET) | 1 | |
| 3214467 | 30 SWITCH-PUSH BUTTON (SHUTDOWN) | 1 | |
| 3214527 | 31 LINK | 4 | |
| 3214470 | 32 CIRCUIT BREAKER (2-AMPERE) | 5 | |
| 3214471 | 33 CIRCUIT BREAKER (6-AMPERE) | 1 | |
| 3214472 | 34 MODULE-INTERFACE | 1 | |
| 3214473 | 35 MODULE-POWER | 1 | |
| 3187611 | 36 MODULE-INPUT | 1 | |
| 3214476 | 37 RELAY | 1 | |
| 3214477 | 38 COVER | 2 | |
| 3214503 | 39 COVER | 2 | |
| 8C6354 | 40 CAP-RECEPTACLE (ET CONNECTOR) | 3 | |
| 2459168 | 41 WASHER (4.7X9X0.8-MM THK) | 4 | |
| 3033858 | 42 MODULE | 1 | |
| 2264038 | 43 TAPE-REFLECTIVE | 3 | |
| 3187645 | 44 CLIP | 3 | |
| 3187724 | 45 DUCT (2-M) | ||
| 3187723 | 46 RAIL (1-M) | ||
| 3242037 | 47 HARNESS AS-PANEL | 1 | |
| 3343108 | 49 FILM-INSTRUCTION (AREA ISOLATION SYSTEM) | 1 | |
| 3234689 | 53 FILM-WARNING (SHOCK, ELECTROCUTION HAZARD) | 1 |
