System And Components
310-3328 RADIO GP-COMMUNICATION -REPEATERFOR USE WITH LOCAL AREA RADIO NETWORK
Group No: 310-3328
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3187723 | 1 RAIL | 29 | |
| 3033860 | 2 BRACKET | 1 | |
| 3214698 | 3 FILM-IDENTIFICATION (2345) | 1 | |
| 8C6354 | 5 CAP-RECEPTACLE (ET CONNECTOR) | 4 | |
| 3267045 | 9 HARNESS AS-RADIO | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 9W1951 | RECEPTACLE-CONNECTOR (9-PIN) | 1 | |
| 3103423 | 10 HARNESS AS-RADIO | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 9W1951 | RECEPTACLE-CONNECTOR (9-PIN) | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | 1 | |
| 3241952 | 11 HARNESS AS-RADIO (CONVERTER) | 1 | |
| 1S9593 | STRAP-CABLE | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(8-CM) | ||
| 3354684 | 13 HARNESS AS-CHASSIS | 1 | |
| 3354685 | 14 HARNESS AS-RADIO | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 9W1951 | RECEPTACLE-CONNECTOR (9-PIN) | 1 | |
| 3055127 | 15 GASKET | 4 | |
| 3053884 | 16 SCREW (M3X10X10-MM) | 16 | |
| 3162770 | 17 WASHER (3X6X0.8-MM THK) | 16 | |
| 3055121 | 18 CLAMP | 4 | |
| 3055122 | 19 TERMINAL | 9 | |
| 1S9593 | 22 STRAP-CABLE | 8 | |
| 3055128 | 23 TERMINAL | 1 | |
| 3214477 | 25 COVER | 1 |
