Assembly
100%

335-4412 WIRING GP-COMMUNICATION -INTERFACE MODULEPART OF 332-0321, 396-0104 INSTALLATION AR-MINEGEM

Group No: 335-4412
Part NumberPart NameQty
6K08061 STRAP-CABLE10
5S73792 BOLT (3/8-16X0.875-IN)4
8T48963 WASHER-HARD (10.2X18.5X2.5-MM THK)22
7D72334 CLIP5
9B72375 BOLT (3/8-16X1.25-IN)8
5P10756 WASHER-HARD (10.2X22.5X3-MM THK)2
6V88017 NUT (3/8-16-THD)4
4S19628 CLIP (LOOP)1
13053009 CLIP12
134822610 BRACKET1
4L645411 BOLT (3/8-16X1-IN)4
6V188912 CLIP (LOOP)2
8T250113 BOLT (3/8-16X2-IN)2
4W762714 SPACER (11X19X37-MM THK)2
4L933715 BOLT (3/8-16X1.5-IN)1
7C824616 SPACER (10.5X20X24-MM THK)1
8T891517 BOLT (3/8-16X3.25-IN)1
9V099918 SPACER (13.8X30X50-MM THK)1
326708219 MOUNT AS1
9S8752NUT-FULL (3/8-16-THD)2
9X625820 SCREW-MACHINE (6-32X0.5-IN)8
4M642521 BOLT (5/16-18X1-IN)3
8T422422 WASHER-HARD (8.8X16X2-MM THK)3
329070723 PLATE1
250355724 SCREW (M5X0.8X12-MM)2
8M277325 CLIP (LOOP)2
5C626626 BOLT (5/8-11X1-IN)1
8T412227 WASHER-HARD (17X32X3.5-MM THK)1
326707628 BRACKET AS1
9S8752NUT-FULL (3/8-16-THD)1
329069629 MOUNT1
4D738830 CLIP1
9X014131 PLUG AS-CONNECTOR (40-PIN)1
3E4367RING-RETAINING1
3E8557BOLT (M5X0.8X39.37-MM)1
9X3490SEAL-CONNECTOR (40-PIN)2
8T873732 PLUG-SEAL40
116011833 CLIP1
326703034 HARNESS AS-CAB1
326705935 CABLE AS1
5P5622WIRE (10-GA, BLACK)(0.4-M)
1082515COVER-TERMINAL1
3214625SLEEVE (20-CM)
1257875TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM)
1257876TUBE-HEAT SHRINK (17.78-MM DIA)(10-CM)
