439-3932 LINES GP-HYDRAULIC -HYDRAC DISCHARGE (CHG -03 THRU -05)Type 3

Group No: 439-3932
Part NumberPart NameQty
4P72331 GROMMET6
8C05692 TEE-O-RING2
8C50533 ADAPTER1
11934504 SPACER (13.5X30X30-MM THK)2
12167505 MANIFOLD2
13861446 FILTER GP-ENGINE OIL1
13861587 VALVE-CHECK (ENGINE OIL)1
17635868 VALVE AS-RELIEF (ENGINE OIL)1
2M9780SEAL-O-RING2
5E4852VALVE-RELIEF (ENGINE OIL)1
28783529 SPACER1
353795310 GROMMET12
423335711 BRACKET AS1
423335812 BRACKET1
423335913 BRACKET1
423901614 TUBE AS1
423901715 TUBE AS1
423901816 TUBE AS1
423901917 TUBE AS1
426056618 BRACKET1
437835619 TUBE AS1
439449020 BRACKET2
443807321 TUBE AS1
469165922 HOSE & TUBE AS1
469166023 HOSE & TUBE AS1
469166124 TUBE AS1
090863525 SPACER (11X22X5-MM THK)10
0S159026 BOLT (3/8-16X2-IN)5
9S875227 NUT-FULL (3/8-16-THD)10
0L207028 BOLT (3/8-16X2.25-IN)1
0S158829 BOLT (3/8-16X1.25-IN)8
165392930 BOLT (3/8-16X1.5-IN)10
0S159431 BOLT (3/8-16X1-IN)9
0S160832 BOLT (3/8-16X3.75-IN)2
243135334 SPACER (11X20X35-MM THK)1
2M978035 SEAL-O-RING7
3D282436 SEAL-O-RING8
3J190737 SEAL-O-RING7
3K036038 SEAL-O-RING2
9X645839 WASHER-HARD (10.2X22.5X3-MM THK)6
3V330840 WASHER-HARD (10.2X20.5X2.5-MM THK)39
6V839841 SEAL-O-RING8
6V863742 CONNECTOR2
6V863943 CONNECTOR1
6V864044 CONNECTOR1
6V872145 ELBOW3
6V878446 TEE-FACE SEAL1
6V900747 ELBOW2
6V918248 ELBOW1
6V974649 SEAL-O-RING12
6V983250 CAP (ORFS)1
6V987751 ELBOW1
7C956052 SPACER (10.5X25X51-MM THK)2
7I831053 CONNECTOR1
7M848554 SEAL-O-RING1
8T188755 CLIP (SLOT)6
8T188856 CLIP (TAB)6
8T188957 CLIP (SLOT)12
8T189058 CLIP (TAB)12
8T538959 ELBOW1
8T687660 ELBOW4
9S419061 PLUG-O-RING (7/8-14-THD)2
9S419162 PLUG (9/16-18-THD)3
