System And Components
310-9494 PAN GP-OILS/N JKH6249-UP
Group No: 310-9494 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3109594 | 1 GUIDE | 1 | |
| 2964703 | 2 BOLT | 16 | |
| 5I7663 | 3 BOLT (M8X1.25X16-MM) | 12 | |
| 7X0796 | 4 LOCKWASHER (10.2X18.4X2.5-MM THK) | 1 | |
| 6V8231 | 5 NUT (M10X1.25-THD) | 1 | |
| 3109595 | 6 PAN AS | 1 | |
| 1764979 | 7 VALVE (ENGINE OIL PAN) | 1 | |
| 5I8067 | 8 WASHER-SEALING | 1 | |
| 1992229 | 9 PLUG-DRAIN (OIL PAN) | 1 | |
| 0952040 | 10 WASHER | 1 | |
| 2941743 | 11 GAUGE AS-OIL LEVEL (DIPSTICK) (ENGINE) | 1 | |
| 5I7842 | 12 GASKET | 1 | |
| 2130677 | 13 SWITCH AS-LIQUID LEVEL (ENGINE OIL) | 1 | |
| 1252968 | 14 SEAL | 1 | |
| 5I4993 | 15 SEAL | 1 |
