System And Components
296-4796 PISTON & ROD GPS/N JKH6249-UP
Group No: 296-4796 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3244238 | 1 PISTON (STANDARD) | 4 | |
| 3244239 | PISTON (0.25-MM OS) | ||
| 3244240 | PISTON (0.5-MM OS) | ||
| 0947134 | 2 PIN | 4 | |
| 5I7667 | 3 RING | 8 | |
| 1786543 | 4 SET-PISTON RING (STANDARD) | 4 | |
| 1786544 | SET-PISTON RING (0.25-MM OS) | ||
| 1786545 | SET-PISTON RING (0.5-MM OS) | ||
| 5511827 | 5 ROD AS | 4 | |
| 0947154 | 5A BOLT (M12X1.25X85-MM) | 2 | |
| 0947516 | 5B NUT (M12X1.25-THD) | 2 | |
| 2964663 | 5C BUSHING | 1 | |
| 2941748 | 6 BEARING | 8 | |
| 2977648 | BEARING (0.25-MM US) | ||
| 2977649 | BEARING (0.50-MM US) | ||
| 2977650 | BEARING (0.75-MM US) |
