305-4954 VALVE MECHANISM GPS/N JKH6249-UP
Group No: 305-4954 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2941684 | 1 VALVE-INLET | 8 | |
| 2941685 | 2 VALVE-EXHAUST | 8 | |
| 2941686 | 3 BASE-ROCKER ARM | 4 | |
| 2941687 | 4 BRIDGE-EXHAUST | 4 | |
| 5I7630 | 5 CAP | 8 | |
| 2941688 | 6 SPRING | 16 | |
| 2941689 | 7 SCREW | 8 | |
| 8T7964 | 8 NUT (M6X1-THD) | 8 | |
| 1992188 | 9 PIN-COTTER | 32 | |
| 1992189 | 10 SEAL-VALVE STEM | 16 | |
| 1992187 | 11 RETAINER | 16 | |
| 3054750 | 12 BRACKET | 4 | |
| 3054751 | 13 SPRING | 3 | |
| 2941693 | 14 PIPE | 1 | |
| 3054931 | 15 SHAFT AS-ROCKER ARM | 1 | |
| 0963741 | CAP | 1 | |
| 3054929 | 16 ROCKER ARM AS | 4 | |
| 0913474 | NUT (M8X1.25-THD) | 1 | |
| 0949525 | SCREW | 1 | |
| 3054927 | 17 ROCKER ARM AS | 4 | |
| 0913474 | NUT (M8X1.25-THD) | 1 | |
| 0949525 | SCREW | 1 | |
| 2941698 | 18 WASHER | 2 | |
| 2941699 | 19 BOLT | 4 | |
| 3054746 | 20 BOLT | 4 | |
| 2941786 | 21 RING | 2 | |
| 2941702 | 22 BOLT | 1 | |
| 3B4505 | 23 LOCKWASHER (8.1X15.4X2-MM THK) | 4 | |
| 3054747 | 24 WASHER | 4 |
