System And Components
265-3613 RADIATOR & HYD OIL COOLER GPS/N WLN1-232; XHR1-177
Group No: 265-3613 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7I2673 | 1 STRAP-CABLE | 4 | |
| 8T4984 | 2 CLAMP-HOSE | 1 | |
| 8T6703 | 3 CLAMP-HOSE | 3 | |
| 0964035 | 4 CLIP | 1 | |
| 1968174 | 5 BAND | 1 | |
| 2459205 | 6 TANK AS-COOLANT (RECOVERY) | 1 | |
| 1713369 | CAP AS (COOLANT RECOVERY) | 1 | |
| 3692193 | 8 GUARD AS-RADIATOR (UPPER, LH) | 1 | |
| 3692194 | 9 GUARD AS-RADIATOR (UPPER, RH) | 1 | |
| 3057604 | 10 RADIATOR & HYD OIL COOLER GP | 1 | |
| 3057627 | 11 HOSE-RADIATOR (UPPER) | 1 | |
| 3057628 | 12 HOSE-RADIATOR (LOWER) | 1 | |
| 3057629 | 13 BRACKET AS | 1 | |
| 3P9847 | 14 CLIP | 1 | |
| 7X2555 | 15 BOLT (M16X2X80-MM) | 3 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 7 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4175 | 19 BOLT (M16X2X90-MM) | 1 | |
| 8T4185 | 20 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4200 | 21 BOLT (M8X1.25X16-MM) | 2 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X8257 | 23 WASHER (17.5X30X3.5-MM THK) | 4 | |
| 7Y1976 | 24 HOSE-WATER (77-CM) | ||
| 5P7174 | 25 SEAL (0.4-M) | ||
| 5P9909 | 26 SEAL (0.5-M) |
