System And Components
305-7604 RADIATOR & HYD OIL COOLER GPS/N WLN1-232; XHR1-177
Group No: 305-7604 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D8159 | 1 PIN AS | 4 | |
| 0935432 | 2 VALVE AS-DRAIN (COOLANT) | 1 | |
| 0964035 | 3 CLIP | 2 | |
| 1968059 | 4 SEAL | 1 | |
| 1968200 | 5 SEAL | 2 | |
| 2040894 | 6 SEAL | 1 | |
| 2040991 | 7 SEAL | 2 | |
| 2041002 | 8 SEAL | 1 | |
| 2459212 | 9 CAP AS-RADIATOR | 1 | |
| 2459216 | 10 BOSS | 4 | |
| 2459217 | 11 CUSHION-RUBBER | 4 | |
| 2459218 | 12 CUSHION-RUBBER | 4 | |
| 2653642 | 13 SEAL | 1 | |
| 3057605 | 14 CORE AS-RADIATOR | 1 | |
| 3057606 | 15 CORE AS-OIL COOLER | 1 | |
| 3057607 | 16 AFTERCOOLER AS | 1 | |
| 3057608 | 17 FRAME AS | 1 | |
| 3057609 | 18 SHROUD AS-RADIATOR | 1 | |
| 3057610 | 19 SEAL | 1 | |
| 3057611 | 20 SEAL | 1 | |
| 3057612 | 21 SEAL | 2 | |
| 3057613 | 22 SEAL | 2 | |
| 3057615 | 23 SEAL | 1 | |
| 3057617 | 24 SEAL | 1 | |
| 3057618 | 25 SEAL | 1 | |
| 3057619 | 26 SEAL | 1 | |
| 3057620 | 27 SEAL | 1 | |
| 3057621 | 28 SCREEN AS (HYDRAULIC OIL COOLER) | 1 | |
| 3057622 | 29 SEAL | 2 | |
| 3057623 | 30 BRACKET | 1 | |
| 3057624 | 31 BRACKET AS | 1 | |
| 5C9553 | 32 BOLT (M6X1X16-MM) | 4 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4137 | 34 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4189 | 35 BOLT (M8X1.25X20-MM) | 7 | |
| 8T4195 | 36 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4224 | 37 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 9X8256 | 38 WASHER (6.6X12X2-MM THK) | 4 | |
| 7Y1976 | 39 HOSE-WATER (95-CM) | ||
| 7Y1976 | 39A HOSE-WATER (8-CM) |
