System And Components
367-5300 RADIATOR & HYD OIL COOLER GPS/N WLN233-UP; XHR178-UP
Group No: 367-5300 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3742038 | 1 CORE AS-AFTERCOOLER | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 5D8159 | 3 PIN AS | 5 | |
| 0964035 | 4 CLIP | 3 | |
| 3477620 | 6 MOUNT | 4 | |
| 3609274 | 7 CAP-RADIATOR | 1 | |
| 3843543 | 8 SEAL-AIR | 2 | |
| 3699794 | 9 SCREEN AS (RADIATOR) | 1 | |
| 3706437 | 10 FRAME AS | 1 | |
| 3706438 | 11 FRAME AS | 1 | |
| 3706439 | 12 FRAME AS | 1 | |
| 3843545 | 13 BRACKET | 1 | |
| 3742036 | 14 CORE AS-RADIATOR | 1 | |
| 3742037 | 15 FRAME AS | 1 | |
| 3742039 | 16 FRAME AS | 1 | |
| 3742040 | 17 FRAME AS | 1 | |
| 3742041 | 18 CORE AS-OIL COOLER (HYDRAULIC) | 1 | |
| 3742042 | 19 SHROUD AS | 1 | |
| 3857920 | 20 SEAL-AIR | 1 | |
| 3857921 | 21 SEAL-AIR | 2 | |
| 3857922 | 22 SEAL-AIR | 1 | |
| 3857923 | 23 SEAL-AIR | 1 | |
| 3857924 | 24 SEAL-AIR | 1 | |
| 3857925 | 25 SEAL-AIR | 2 | |
| 3857926 | 26 SEAL-AIR | 1 | |
| 3857927 | 27 SEAL-AIR | 1 | |
| 3857928 | 28 SEAL-AIR | 1 | |
| 3857929 | 29 SEAL-AIR | 1 | |
| 3857930 | 30 SEAL-AIR | 1 | |
| 3857932 | 31 SEAL-AIR | 1 | |
| 3857934 | 32 SEAL-AIR | 1 | |
| 3857939 | 33 SCREEN AS (AFTERCOOLER) | 1 | |
| 1156433 | 35 WASHER (11X50X6-MM THK) | 4 | |
| 7X0589 | 36 WASHER-HARD (12X28.5X5-MM THK) | 3 | |
| 7X7729 | 37 WASHER (11X25X3-MM THK) | 2 | |
| 8T4121 | 38 WASHER-HARD (11X21X2.5-MM THK) | 31 | |
| 8T4136 | 39 BOLT (M10X1.5X25-MM) | 31 | |
| 8T4186 | 40 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4195 | 41 BOLT (M10X1.5X30-MM) | 5 | |
| 8T4224 | 42 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 43 BOLT (M8X1.25X25-MM) | 8 | |
| 7Y1976 | 44 HOSE-WATER (120-CM) |
