System And Components
296-4794 FILTER GP-FUELS/N JKH6249-UP
Group No: 296-4794 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0994437 | 1 GASKET | 19 | |
| 0995041 | 2 BOLT (M14X1.5X27-MM) | 8 | |
| 2941811 | 3 WASHER (13.5-MM OD) | 2 | |
| 2964749 | 4 HOSE | 1 | |
| 1375541 | 5 PUMP GP-FUEL PRIMING (MANUAL) | 1 | |
| 0617539 | SEAL-O-RING | 1 | |
| 2293218 | VALVE AS (FUEL PRIMING PUMP) | 2 | |
| 2941820 | 6 GASKET (FUEL PRIMING PUMP) | 1 | |
| 1992241 | 7 BOLT | 1 | |
| 2941821 | 8 BOLT (M8X1.25X35.5-MM) | 1 | |
| 2941822 | 9 BASE | 1 | |
| 2964750 | 10 BOLT (M10X1.25-THD) | 4 | |
| 1R0751 | 11 FILTER-FUEL (ADVANCED EFFICIENCY) | 2 | |
| 3054886 | 12 HOSE | 1 | |
| 2964752 | 13 BRACKET | 1 | |
| 2964753 | 14 BOLT (M10X1.5-THD) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 2941819 | 17 HOSE | 1 | |
| 2964754 | 18 TUBE | 1 | |
| 1905830 | 19 TUBE | 1 | |
| 0949725 | 20 PLUG | 2 | |
| 3109529 | 21 BRACKET | 1 | |
| 3109530 | 22 HOSE | 1 | |
| 0952038 | 23 WASHER (7.8X13.5X2-MM THK) | 2 | |
| 2139433 | 24 BOLT (M10X1.5X45-MM) | 2 | |
| 2941838 | 25 BRACKET | 1 | |
| 2941831 | 26 CLAMP | 3 | |
| 3109531 | 27 CLAMP | 1 | |
| 2977706 | 28 BOLT (M6X1X64-MM) | 2 | |
| 3B4504 | 29 LOCKWASHER | 2 | |
| 5C2890 | 30 NUT (M6X1-THD) | 2 | |
| 2941809 | 33 BOLT | 1 | |
| 2941844 | 34 BOLT (M12X1.75X28-MM) | 1 | |
| 2941845 | 35 BOLT (M12X1.25X38-MM) | 1 | |
| 2977660 | 37 NUT (M8-THD) | 1 | |
| 5I8058 | 38 CONNECTOR | 1 | |
| 3109534 | 39 CONNECTOR | 1 | |
| 3109533 | 40 ADAPTER | 2 | |
| 6V5215 | 41 BOLT (M8X1.25X16-MM) | 2 | |
| 2941837 | 43 BRACKET | 1 | |
| 3054901 | 44 SEAL-O-RING | 1 | |
| 3054902 | 45 CONNECTOR | 1 | |
| 3054900 | 46 PIPE | 1 | |
| 1252983 | 48 FITTING | 1 | |
| 2941804 | 49 SEAL-O-RING | 3 |
