System And Components
260-7222 PUMP GP-FUEL TRANSFERS/N WLN1-UP; XHR1-UP
Group No: 260-7222 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3122645 | 1 SWITCH AS-LIQUID LEVEL (FUEL TANK SHUTOFF)(FUEL TANK SHUTOFF) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 9M7958 | 2 CLAMP-HOSE | 6 | |
| 0065707 | 3 ELBOW-PIPE | 1 | |
| 1056701 | 4 CONNECTOR-HOSE | 3 | |
| 3245761 | 5 COVER AS | 1 | |
| 1358572 | 6 BOLT AS | 2 | |
| 4423946 | 7 VALVE AS (FOOT) | 1 | |
| 2838952 | 8 BLOCK | 1 | |
| 3012477 | 9 CONTROL GP-REFUELING PUMP | 1 | |
| 3012478 | 10 PUMP GP-FUEL TRANSFER | 1 | |
| 3012524 | 11 CONNECTOR-HOSE | 2 | |
| 3012526 | 12 SHEET AS | 1 | |
| 3012527 | 13 SEAL-WASHER | 2 | |
| 1325789 | 14 CLIP (LADDER) | 1 | |
| 5C9553 | 15 BOLT (M6X1X16-MM) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4189 | 18 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4195 | 19 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6466 | 21 BOLT (M10X1.5X60-MM) | 2 | |
| 9X8256 | 22 WASHER (6.6X12X2-MM THK) | 2 | |
| 4571156 | 23 HOSE (300-CM) | ||
| 4571156 | 23A HOSE (36-CM) | ||
| 4571156 | 23B HOSE (23-CM) | ||
| 3S2093 | 24 STRAP-CABLE | 2 | |
| 7K1181 | 25 STRAP-CABLE | 2 | |
| 3099690 | 26 FILM-INFORMATION (READ OMM) | 1 |
