System And Components
153-2522 LAMP GP-FLOODS/N WLN1-UP; XHR1-UP
Group No: 153-2522 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V5210 | 1 SCREW-MACHINE (M4X0.7X10-MM) | 2 | |
| 3B4501 | 2 LOCKWASHER | 2 | |
| 3519918 | 3 LAMP-HALOGEN (24-VOLT, 70-WATT) | 1 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4244 | 5 NUT (M12X1.75-THD) | 1 | |
| 1747791 | 6 SCREW-TAPPING | 1 | |
| 9B0453 | 7 LOCKWASHER | 1 | |
| 1706993 | 8 COVER | 1 | |
| 1803861 | 9 SCREW-TAPPING | 4 | |
| 1709417 | 10 LENS AS (FLOODLIGHT) | 1 | |
| 1709418 | 11 BAND | 1 |
