Assembly
100%

157-9162 SENSOR & MTG GP-POSITION -STICKS/N WLN1-UP; XHR1-UP

Group No: 157-9162 · Commonality
Part NumberPart NameQty
12000441 SENSOR AS-POSITION (STICK)1
1028803KIT-RECEPTACLE (3-PIN)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)3
13477212 BOLT (M6X1X12-MM)2
9X82563 WASHER (6.6X12X2-MM THK)8
3T08494 BOLT-SOCKET HEAD (M6X1X25-MM)4
6V73575 BOLT (M6X1X25-MM)1
15791636 LEVER AS1
15791657 ROD AS1
5C2890NUT (M6X1-THD)2
8C3111ROD END2
1579167BAR1
3S20938 STRAP-CABLE1
8T41389 BOLT (M6X1X20-MM)1
