Assembly
100%

202-1584 SENSOR & MTG GP-POSITION -OFFSET BOOMS/N WLN1-UP; XHR1-UP

Group No: 202-1584 · Commonality
Part NumberPart NameQty
13477211 BOLT (M6X1X12-MM)2
9X82562 WASHER (6.6X12X2-MM THK)10
12000443 SENSOR AS-POSITION (BOOM)1
1028803KIT-RECEPTACLE (3-PIN)1
1863735PIN-CONNECTOR (16-GA TO 18-GA)3
3T08494 BOLT-SOCKET HEAD (M6X1X25-MM)4
21163555 LEVER AS1
5C2890NUT (M6X1-THD)1
15792336 LINKAGE AS1
5C2890NUT (M6X1-THD)2
8C3111ROD END2
8T41387 BOLT (M6X1X20-MM)2
20832398 COVER AS1
8T4224WASHER-HARD (8.8X16X2-MM THK)4
8T41719 BOLT (M6X1X12-MM)4
