System And Components
267-7775 WIRING GP-CABS/N WLN1-UP; XHR1-UP
Group No: 267-7775 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 1210987 | 2 SOCKET-AUXILIARY POWER (12-VOLT, 7-AMPERE) | 1 | |
| 3407160 | 3 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 2677901 | 4 HARNESS AS-CAB | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 1 | |
| 1532602 | RECEPTACLE-CONNECTOR (1-PIN) | 1 | |
| 1532631 | TERMINAL (14-GA TO 20-GA) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 2070210 | 5 GROMMET | 1 | |
| 8T6693 | 6 SCREW-MACHINE (M5X0.8X16-MM) | 2 | |
| 8T0328 | 7 WASHER-HARD (5.5X10X1-MM THK) | 2 |
