System And Components
342-3247 WIRING GP-CONSOLE -OFFSET BOOMS/N WLN1-UP; XHR1-UP
Group No: 342-3247 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1636795 | 2 STRAP-CABLE | 1 | |
| 2833074 | 3 SWITCH AS-TOGGLE (AUTO/MANUAL ENG SPEED CONTROL) | 1 | |
| 3423248 | 4 HARNESS AS-PUMP | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 2434508 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 2L8074 | TERMINAL-RING (14-GA TO 16-GA, NO. 6 SCREW) | 5 | |
| 3423249 | 5 BRACKET AS | 1 | |
| 9X2042 | 6 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 |
