System And Components
286-6084 BOX GP-FUEL TRANSFERS/N WLN1-UP; XHR1-UP
Group No: 286-6084 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S1647 | 1 GROMMET | 1 | |
| 2866063 | 2 SHEET AS | 1 | |
| 2866064 | 3 SHEET AS | 1 | |
| 2982932 | 4 GROMMET | 1 | |
| 2983052 | 5 ROD AS | 1 | |
| 3205769 | 6 SEAL | 1 | |
| 3205770 | 7 SEAL | 2 | |
| 3205771 | 8 SEAL | 1 | |
| 3374726 | 9 LINER | 1 | |
| 3397291 | 10 LINER | 1 | |
| 3374729 | 11 LINER | 1 | |
| 3B4618 | 12 PIN-COTTER | 1 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 14 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 3485409 | 16 SEAL (5-DM) |
