System And Components
199-4692 GEAR & BEARING GP-SWINGS/N WLN1-UP; XHR1-UP
Group No: 199-4692 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1215204 | 1 RETAINER | 1 | |
| 0990913 | 2 CLAMP-HOSE | 1 | |
| 1215203 | 3 BOOT | 1 | |
| 8T4136 | 4 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4121 | 5 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 5K9243 | 6 ELBOW-FLARED | 2 | |
| 7X2555 | 7 BOLT (M16X2X80-MM) | 34 | |
| 0951299 | 8 DOWEL | 1 | |
| 8T4199 | 9 BOLT (M8X1.25X12-MM) | 2 | |
| 4N9170 | 10 CLIP | 2 | |
| 3B8489 | 11 ADAPTER | 1 | |
| 4I7446 | 12 GASKET | 1 | |
| 4I7326 | 13 STRIP | 1 | |
| 1912665 | 14 TUBE AS | 1 | |
| 2291079 | 15 GEAR & BEARING GP-SWING (127-BEARING) | 1 | |
| 8T0357 | 16 BOLT (M16X2X70-MM) | 38 | |
| 0859310 | 17 SPACER (16.6X32X26-MM THK) | 38 | |
| 1U8846 | 18 SEALANT-GASKET | ||
| 1912544 | 19 WASHER (16.6X32X5-MM THK) | 34 |
