System And Components
385-2834 CYLINDER & SEAL GP-BUCKETS/N WLN1-UP; XHR1-UP
Group No: 385-2834 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3904219 | 1 CYLINDER AS | 1 | |
| 2291095 | 1A BUSHING | 1 | |
| 3904220 | 2 ROD AS | 1 | |
| 2487857 | 2A BUSHING | 1 | |
| 3904221 | 3 HEAD | 1 | |
| 3904158 | 4 BUSHING | 1 | |
| 3904157 | 5 RING-RETAINING | 1 | |
| 3904159 | 6 RING-SNAP | 1 | |
| 3904225 | 7 PISTON | 1 | |
| 3904226 | 8 SETSCREW-SOCKET (M10X1.5X10-MM) | 1 | |
| 3852890 | 9 BALL | 1 | |
| 3E6910 | 10 BOLT-SOCKET HEAD (M12X1.75X70-MM) | 15 | |
| 1661492 | 11 SEAL-LIP TYPE | 2 | |
| 2357679 | 12 SEAL-LIP TYPE | 2 | |
| 3B8489 | 13 ADAPTER | 2 | |
| 4161295 | 14 SEAL-WIPER | 1 | |
| 4161296 | 15 SEAL-U-CUP | 1 | |
| 4161298 | 16 SEAL-BUFFER | 1 | |
| 4161297 | 17 RING-BACKUP | 1 | |
| 4161299 | 18 SEAL-O-RING | 1 | |
| 4161300 | 19 RING-BACKUP | 1 | |
| 4161302 | 20 SEAL AS-PISTON | 1 | |
| 4161301 | 21 RING-WEAR | 2 | |
| 4161303 | 22 RING-WEAR | 2 | |
| 3904227 | KIT-SEAL (BUCKET CYLINDER) | 1 |
