System And Components
385-2831 CYLINDER & SEAL GP-STICKS/N WLN1-UP; XHR1-UP
Group No: 385-2831 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3904202 | 1 CYLINDER AS-STICK | 1 | |
| 2291093 | 1A BUSHING | 1 | |
| 3904203 | 2 ROD AS | 1 | |
| 2291093 | 2A BUSHING | 1 | |
| 3904204 | 3 HEAD | 1 | |
| 3852900 | 4 BUSHING | 1 | |
| 3852899 | 5 RING-RETAINING | 1 | |
| 3904207 | 6 STOP | 1 | |
| 3904208 | 7 PISTON | 1 | |
| 3852905 | 8 RING-SNAP | 1 | |
| 3852922 | 9 BALL | 1 | |
| 4229120 | 10 SETSCREW-HEX SOCKET | 1 | |
| 3852910 | 11 RING-RETAINING | 1 | |
| 3852920 | 12 RING-RETAINING | 1 | |
| 3904215 | 13 STOP | 1 | |
| 0950703 | 14 BOLT-SOCKET HEAD (M16X2X75-MM) | 12 | |
| 1661492 | 15 SEAL-LIP TYPE | 4 | |
| 3B8489 | 16 ADAPTER | 1 | |
| 8T6763 | 17 PLUG-PIPE (1/4-18-THD) | 1 | |
| 4161284 | 18 SEAL-WIPER | 1 | |
| 4161285 | 19 SEAL-U-CUP | 1 | |
| 4161287 | 20 SEAL-BUFFER | 1 | |
| 4161286 | 21 RING-BACKUP | 1 | |
| 4161288 | 22 SEAL-O-RING | 1 | |
| 4161289 | 23 RING-BACKUP | 1 | |
| 4161291 | 24 SEAL AS | 1 | |
| 4161290 | 25 RING-WEAR | 2 | |
| 4161292 | 26 RING-WEAR | 2 | |
| 4161293 | 27 RING-SEAL | 1 | |
| 4161294 | 28 RING-SEAL | 1 | |
| 3937949 | KIT-SEAL (STICK CYLINDER) |
