System And Components
289-7720 CYLINDER GP-BOOMS/N WLN1-UP; XHR1-UP
Group No: 289-7720 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X7301 | 1 SEAL AS | 1 | |
| 0990661 | 2 RING-RETAINING | 1 | |
| 0990674 | 3 RING | 1 | |
| 1438031 | 4 RING | 2 | |
| 1438150 | 5 LOCKNUT-SPECIAL | 1 | |
| 1659284 | 6 SEAL-LIP TYPE | 1 | |
| 1709842 | 7 SEAL-BUFFER | 1 | |
| 1709858 | 8 SEAL-U-CUP | 1 | |
| 1733350 | 9 STOP | 1 | |
| 1733351 | 10 HEAD | 1 | |
| 2835926 | 11 PISTON | 1 | |
| 2835927 | 12 RING | 2 | |
| 2835971 | 13 RING-SEAL | 1 | |
| 2836040 | 14 ROD AS | 1 | |
| 2736813 | 14A BUSHING | 1 | |
| 2897721 | 15 CYLINDER AS | 1 | |
| 2736811 | 15A BUSHING | 1 | |
| 0951627 | 16 SEAL-O-RING | 2 | |
| 0951674 | 17 SEAL-O-RING | 1 | |
| 0963467 | 18 RING-BACKUP | 1 | |
| 0990660 | 19 RING-BACKUP | 3 | |
| 1140750 | 20 BUSHING | 1 | |
| 2897733 | KIT-SEAL (BOOM CYLINDER) | 1 |
