System And Components
384-5097 CYLINDER GP-BOOM -OFFSETS/N WLN1-UP; XHR1-UP
Group No: 384-5097 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0990661 | 1 RING-RETAINING | 1 | |
| 1057377 | 2 RING | 1 | |
| 1659284 | 3 SEAL-LIP TYPE | 1 | |
| 2003358 | 4 HEAD | 1 | |
| 2003359 | 5 PISTON | 1 | |
| 3264417 | 6 LOCKNUT (M60X2-THD) | 1 | |
| 3494115 | 7 SEAL-BUFFER | 1 | |
| 3494117 | 8 SEAL-U-CUP | 1 | |
| 3845098 | 9 CYLINDER AS-HYDRAULIC | 1 | |
| 3815285 | 9A BUSHING | 1 | |
| 3845104 | 10 ROD AS | 1 | |
| 2909178 | 10A BUSHING | 1 | |
| 0951631 | 11 SEAL-O-RING | 1 | |
| 0951678 | 12 SEAL-O-RING | 1 | |
| 0963467 | 13 RING-BACKUP | 1 | |
| 1140750 | 14 BUSHING | 1 | |
| 1505884 | 15 RING | 1 | |
| 1799771 | 16 RING | 2 | |
| 7Y4633 | 17 RING-BACKUP | 1 | |
| 9X3595 | 18 SEAL AS | 1 | |
| 3949688 | KIT-SEAL (BOOM CYLINDER)(OFFSET) | 1 |
