System And Components
300-6024 CYLINDER GP-COUPLERS/N WLN1-UP; XHR1-UP
Group No: 300-6024 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 ADAPTER | 1 | |
| 9F2167 | 2 SCREW-PURGE (3/8-24X1.164-IN) | 1 | |
| 3465585 | 3 BEARING | 1 | |
| 3465586 | 4 BEARING (TRUNNION) | 2 | |
| 3465587 | 5 PISTON | 1 | |
| 3465588 | 6 HEAD | 1 | |
| 3465589 | 7 ROD AS | 1 | |
| 3465590 | 8 TUBE AS | 1 | |
| 3466711 | 9 VALVE AS-COUNTERBALANCE | 1 | |
| 0102570 | 10 SETSCREW (1/4-20X0.375-IN) | 3 | |
| 2D4534 | 11 BOLT-SOCKET HEAD (3/8-16X1-IN) | 12 | |
| 9S8002 | 12 PLUG (7/16-20-THD) | 3 | |
| 9S8004 | 13 PLUG (9/16-18-THD) | 1 | |
| 3465584 | KIT-SEAL (COUPLER CYLINDER) | 1 | |
| 1611980 | KIT-SERVICE (COUNTERBALANCE VALVE) | 1 |
