System And Components
289-7713 CYLINDER GP-STICKS/N WLN1-UP; XHR1-UP
Group No: 289-7713 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3228726 | 1 STOP | 1 | |
| 9X3592 | 2 SEAL AS | 1 | |
| 1038441 | 3 RING-RETAINING | 1 | |
| 1038442 | 4 RING | 1 | |
| 3228725 | 5 STOP | 1 | |
| 1232002 | 6 RING | 1 | |
| 1438027 | 7 RING | 2 | |
| 1438151 | 8 LOCKNUT-SPECIAL | 1 | |
| 1733358 | 9 HEAD | 1 | |
| 3582103 | 10 ROD AS | 1 | |
| 2291093 | 10A BUSHING | 1 | |
| 2835939 | 11 PISTON | 1 | |
| 2835940 | 12 RING | 2 | |
| 2835972 | 13 RING-SEAL | 1 | |
| 2897714 | 14 CYLINDER AS | 1 | |
| 3439327 | 14A BUSHING | 1 | |
| 0961054 | 15 RING-BACKUP | 1 | |
| 0968139 | 16 RING-RETAINING | 1 | |
| 1140755 | 17 BUSHING | 1 | |
| 1659285 | 18 SEAL-LIP TYPE | 1 | |
| 1709843 | 19 SEAL-BUFFER | 1 | |
| 1709859 | 20 SEAL-U-CUP | 1 | |
| 0951628 | 21 SEAL-O-RING | 2 | |
| 0951676 | 22 SEAL-O-RING | 1 | |
| 0990681 | 23 RING-BACKUP | 3 | |
| 8T4241 | 24 RING-RETAINING | 2 | |
| 2897716 | KIT-SEAL (STICK CYLINDER) | 1 |
