System And Components
353-7562 WIRING GP-MONITOR -OBJECT DETECTIONType 1
Group No: 353-7562
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 24 | |
| 1678748 | 2 PLATE | 1 | |
| 2922898 | 3 CONDUIT (88-CM) | 1 | |
| 3155391 | 4 NUT (M50X1.5-THD) | 1 | |
| 3196830 | 5 HARNESS AS-MONITOR (CAMERA) | 1 | |
| 3457113 | 6 SWITCH AS-ROCKER (WORK AREA VISUAL SYSTEM) | 1 | |
| 3457489 | 7 HARNESS AS-MONITOR | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 3S2093 | STRAP-CABLE | 1 | |
| 8T8736 | RECEPTACLE-CONNECTOR (9-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 22 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 1342540 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1740503 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 2187136 | SLEEVE (52-CM) | ||
| 3489226 | 8 GROMMET AS | 1 | |
| 3524693 | 9 BRACKET | 1 | |
| 3524694 | 10 BRACKET | 1 | |
| 3537563 | 11 HARNESS AS-CAB | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 2 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E7996 | PLUG-CONNECTOR (6-PIN) | 1 | |
| 7T0093 | PIN-CONNECTOR (12-GA TO 14-GA) | 4 | |
| 7T0094 | SOCKET-CONNECTOR (12-GA TO 14-GA) | 3 | |
| 8T8737 | PLUG-SEAL | 36 | |
| 0655071 | TERMINAL-BLADE (14-GA TO 16-GA) | 4 | |
| 1138491 | FUSE (15-AMPERE) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(20-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(20-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 11 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 11 | |
| 1311492 | TERMINAL AS-RING (6-GA TO 8-GA) | 1 | |
| 2L8054 | TERMINAL-RING (6-GA, 1/2-IN SCREW) | 1 | |
| 2L8061 | TERMINAL-RING (8-GA, 1/2-IN SCREW) | 1 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(4-CM) | ||
| 1311494 | TERMINAL AS | 2 | |
| 2L8065 | TERMINAL-RING (10-GA TO 12-GA, NO. 8 SCREW) | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA) | 4 | |
| 1311500 | TERMINAL AS-RING | 4 | |
| 2L8071 | TERMINAL-RING (10-GA TO 12-GA, 1/2-IN SCREW) | 1 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(4-CM) | ||
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 1 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552256 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 2110052 | NUT (1-11/16-18-THD) | 1 | |
| 3045284 | HOLDER-FUSE | 1 | |
| 3100674 | LOCKWASHER | 1 | |
| 3522018 | RESISTOR AS | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 1740503 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 3559048 | 12 DISPLAY GP-MONITOR (OBJECT DETECTION) | 1 | |
| 2613223 | 13 CABLE AS-COMMUNICATION | 4 | |
| 2D0388 | 14 GROMMET (25.4-MM ID) | 1 | |
| 3482163 | 15 PEDESTAL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 7T1099 | LINK | 3 | |
| 3Y8100 | 16 BOLT (3/8-16X0.87-IN) | 4 | |
| 4B4863 | 17 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 4D3100 | 18 GROMMET | 2 | |
| 4P7429 | 19 CLIP | 1 | |
| 5P4116 | 20 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6T3644 | 21 CIRCUIT BREAKER AS (20-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 7U4892 | 22 SCREW (8-32X0.75-IN) | 2 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 9X2044 | 24 SCREW-TRUSS HEAD (M6X1X16-MM) | 4 | |
| 1P0810 | 25 TAPE-ELECTRICAL (30-CM EACH) | ||
| 1P0810 | 25A TAPE-ELECTRICAL (15-CM) |
