281-1640 CYLINDER HEAD ASS/N TXL1-UP; L4X1-UP

Group No: 281-1640 · Commonality
Part NumberPart NameQty
12273751 GUIDE-VALVE (STANDARD)24
1220447GUIDE-VALVE (0.51-MM OS)
1228612GUIDE-VALVE (0.13-MM OS)
21655822 BUSHING (STANDARD)7
2170751BUSHING (0.25-MM OS)
2170752BUSHING (0.762-MM OS)
2613429BUSHING (1.778-MM OS)
2613430BUSHING (1.27-MM OS)
30035653 INSERT-VALVE SEAT (EXHAUST)12
26349204 SLEEVE-INJECTOR (INLET)6
28039796 INSERT-VALVE SEAT (INLET)12
2884881INSERT-VALVE SEAT (0.51-MM OS, INLET)
2884882INSERT-VALVE SEAT (0.76-MM OS, INLET)
16629047 SEAL-O-RING12
3B06238 PLUG-CUP (25.73-MM OD)17
3B06459 PLUG-CUP (32.08-MM OD)20
8T675710 PLUG-PIPE3
9X743011 SEAL-O-RING6
448329712 HEAD-CYLINDER1
