System And Components
282-0671 GEAR GP-FRONTS/N L4X1-UP
Group No: 282-0671 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P4142 | 1 BOLT-LOCKING (3/8-16X1.5-IN) | 2 | |
| 6I3624 | 2 PLATE-THRUST | 2 | |
| 6I3625 | 3 GEAR AS (71-TEETH) | 1 | |
| 1018468 | BUSHING | 1 | |
| 1025861 | 4 PLATE-THRUST | 1 | |
| 1070583 | 5 BOLT-LOCKING (1/4-20X0.87-IN) | 3 | |
| 1129217 | 6 PLATE-THRUST | 1 | |
| 1178801 | 7 SEAL-O-RING | 1 | |
| 1261756 | 8 BOLT-LOCKING (5/16-18X0.875-IN) | 10 | |
| 1304701 | 9 GEAR AS (56-TEETH) | 1 | |
| 1304698 | BUSHING | 1 | |
| 1878979 | 10 GEAR AS (105, 63-TEETH) | 1 | |
| 1B8705 | KEY-WOODRUFF | 1 | |
| 6I4582 | GEAR (63-TEETH) | 1 | |
| 1282661 | BUSHING | 1 | |
| 1499110 | 11 GEAR-OIL PUMP DRIVE (69-TEETH)(ENGINE) | 1 | |
| 1515966 | 12 SHAFT AS-STUB | 1 | |
| 6I3623 | DOWEL | 1 | |
| 1583416 | 13 SHAFT-STUB | 1 | |
| 1591533 | 14 PLATE-SEALING | 1 | |
| 1598524 | 15 ADAPTER AS | 1 | |
| 6V3677 | DOWEL | 1 | |
| 1974971 | 16 SHAFT-STUB | 1 | |
| 2493360 | 17 GEAR GP-CAMSHAFT (96-TEETH) | 1 | |
| 0313185 | 18 BOLT-12 POINT HEAD (5/8-11X3-IN) | 6 | |
| 0S1571 | 19 BOLT (3/8-16X1.75-IN) | 1 | |
| 1B8705 | 20 KEY-WOODRUFF | 1 | |
| 1P7346 | 21 WASHER-HARD (10.2X35X6-MM THK) | 1 | |
| 2J3118 | 22 BOLT-LOCKING (3/8-16X1.25-IN) | 5 | |
| 5E8771 | 23 SEAL-O-RING | 1 | |
| 9S8752 | 24 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6458 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 12 |
