System And Components
347-1507 HOUSING GP-FLYWHEELS/N TXL1-UP; L4X1-UP
Group No: 347-1507 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3710611 | 1 HOUSING AS-FLYWHEEL | 1 | |
| 8M9315 | BUSHING | 2 | |
| 9S8005 | PLUG (3/4-16-THD) | 4 | |
| 2385080 | SEAL-O-RING | 4 | |
| 8T6765 | PLUG-PIPE (1/4-18-THD) | 2 | |
| 9S8002 | PLUG (7/16-20-THD) | 4 | |
| 2147566 | SEAL-O-RING | 4 | |
| 1W3136 | BAFFLE | 1 | |
| 1555619 | 2 GASKET | 1 | |
| 1753721 | 3 COVER | 1 | |
| 3299616 | 4 PLUG GP-FLYWHEEL HOUSING | 1 | |
| 0S1592 | 5 BOLT (5/8-11X1.25-IN) | 2 | |
| 0S1594 | 6 BOLT (3/8-16X1-IN) | 1 | |
| 0S1619 | 7 BOLT (3/8-16X3-IN) | 1 | |
| 7N8374 | 8 COVER-PUMP | 1 | |
| 1653930 | 9 BOLT (3/8-16X1.625-IN) | 6 | |
| 1653932 | 10 BOLT (3/8-16X2-IN) | 5 | |
| 1653936 | 11 BOLT (3/8-16X4.5-IN) | 2 | |
| 2348937 | 12 SEAL-INTEGRAL | 1 | |
| 2H3855 | 13 BOLT (1/2-13X0.875-IN) | 2 | |
| 2P2772 | 14 COVER | 1 | |
| 4M0189 | 15 SEAL-O-RING | 1 | |
| 5J5793 | 16 BOLT-12 POINT HEAD (1/2-13X2-IN) | 1 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 5P8247 | 19 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 6V8260 | 20 SEAL-O-RING | 1 | |
| 9K7290 | 21 BOLT-12 POINT HEAD (1/2-13X3.25-IN) | 8 | |
| 3190785 | 22 SEAL GP-CRANKSHAFT (REAR)(FLYWHEEL HOUSING) | 1 |
