System And Components
233-4890 PAN GP-OIL -REAR SUMPS/N TXL1-UP; L4X1-UP
Group No: 233-4890 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7373 | 1 TUBE AS | 1 | |
| 3196234 | 2 PLUG AS | 2 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 9X6451 | 3 PLUG-DRAIN (MAGNETIC)(ENGINE OIL PAN) | 3 | |
| 1096547 | 4 TUBE AS | 1 | |
| 1152355 | 5 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 1152365 | 6 BRACKET-TUBE | 1 | |
| 1182019 | 7 UNDERFRAME AS | 1 | |
| 1685248 | 8 SEAL-ISOLATION | 1 | |
| 2273006 | 9 PAN-OIL | 1 | |
| 0L1351 | 10 BOLT (3/8-16X0.875-IN)(MARKED Z) | 5 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1591 | 12 BOLT (3/8-16X1.5-IN)(MARKED Y) | 4 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN)(MARKED X) | 3 | |
| 5P5846 | 14 SEAL-O-RING | 1 | |
| 5P8068 | 15 SEAL-O-RING | 1 | |
| 1210145 | 16 SEAL-O-RING | 3 | |
| 2K4973 | 17 LOCKNUT (3/8-16-THD) | 2 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 9X6458 | 19 WASHER-HARD (10.2X22.5X3-MM THK) | 9 |
