System And Components
364-7158 PANEL GP-SOUND SUPPRESSIONS/N T4P1-UP
Group No: 364-7158 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0950817 | 1 LOCKWASHER | 4 | |
| 1564522 | 2 WASHER-HARD (14X30X3-MM THK) | 4 | |
| 3438800 | 3 PANEL AS | 1 | |
| 3438803 | 4 INSULATION | 1 | |
| 3543186 | 5 INSULATION | 1 | |
| 3647157 | 6 PANEL (INTERNAL) | 1 | |
| 1560283 | 7 WASHER-HARD (8.4X35X2.5-MM THK) | 1 | |
| 5P4116 | 8 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 6V7743 | 9 LOCKNUT (M6X1-THD) | 7 | |
| 6V9189 | 10 LOCKNUT (M8X1.25-THD) | 1 | |
| 7X0465 | 11 BOLT (M6X1X100-MM) | 3 | |
| 7X0586 | 12 WASHER-HARD (7.2X32X2-MM THK) | 7 | |
| 8R8847 | 13 RETAINER-SPRING | 4 | |
| 8T3844 | 14 BOLT (M6X1X70-MM) | 4 | |
| 8T4177 | 15 BOLT (M8X1.25X90-MM) | 1 | |
| 8T4648 | 16 BOLT (M12X1.75X70-MM) | 4 | |
| 9X6165 | 17 WASHER (6.5X22X2.5-MM THK) | 7 |
