System And Components
342-6368 PISTON & ROD GPS/N TXL1-UP; L4X1-UP
Group No: 342-6368 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1515925 | 1 BOLT (7/16-14-THD) | 1 | |
| 5245565 | 2 PIN-PISTON | 1 | |
| 2243245 | 3 ROD AS | 1 | |
| 2133217 | 3A BOLT (M11X1.25X84-MM) | 4 | |
| 2194458 | 3B PIN-DOWEL | 2 | |
| 2296259 | 3C BEARING | 1 | |
| 2502940 | 4 RETAINER-PIN | 2 | |
| 2613450 | 5 BEARING-CONNECTING ROD (STANDARD) | 1 | |
| 2323235 | BEARING-CONNECTING ROD (0.64-MM US) | 1 | |
| 2323236 | BEARING-CONNECTING ROD (1.27-MM US) | 1 | |
| 2764637 | 6 TUBE AS-OIL JET | 1 | |
| 3064014 | 7 RING-PISTON (OIL) | 1 | |
| 3064016 | 8 RING-PISTON (INTERMEDIATE) | 1 | |
| 3104188 | 9 RING-PISTON (TOP) | 1 | |
| 3426359 | 10 BODY AS-PISTON | 1 |
