System And Components
291-9044 FAN GP-SUCTIONS/N T4P1-UP
Group No: 291-9044 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4956 | 1 BOLT (M12X1.75X35-MM) | 4 | |
| 3418597 | 2 BRACKET | 2 | |
| 3482830 | 3 BOSS-MOUNTING | 1 | |
| 3483058 | 4 BRACKET | 1 | |
| 3529305 | 5 NUT-SPRING | 4 | |
| 3624569 | 6 SUPPORT AS | 1 | |
| 7T1099 | LINK | 5 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 12 | |
| 1599539 | NUT-WELD (M6X1-THD) | 8 | |
| 3624588 | 7 BRACKET | 1 | |
| 3624591 | 8 SPIDER AS-FAN (11-BLADE) | 1 | |
| 5P1076 | 9 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 6 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4189 | 13 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4122 | 14 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4908 | 15 BOLT (M8X1.25X25-MM) | 2 | |
| 2K4821 | 16 LOCKNUT (5/8-18-THD) | 1 |
