System And Components
291-8922 LINES GP-COOLANTS/N T4P1-UP
Group No: 291-8922 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4156334 | 1 HOSE (100-CM) | ||
| 8T0154 | 2 CLAMP-HOSE | 3 | |
| 0057889 | 3 VALVE AS-DRAIN (ENGINE COOLANT) | 1 | |
| 1570670 | 4 CAP-DUST | 1 | |
| 4184412 | 5 TUBE | 1 | |
| 9X2133 | 6 HOSE (40-CM) | ||
| 1932120 | 7 GROMMET | 4 | |
| 2086054 | 8 CLAMP-T BOLT | 9 | |
| 3006036 | 9 CLAMP-BAND | 2 | |
| 4184418 | 10 TUBE AS | 1 | |
| 3341478 | 11 TUBE | 1 | |
| 3341480 | 12 TUBE | 1 | |
| 3341484 | 13 TUBE AS | 1 | |
| 3399660 | 14 ELBOW | 1 | |
| 3399661 | 15 ELBOW | 1 | |
| 3718113 | 16 HOSE (116-CM) | ||
| 3426298 | 17 HOSE | 3 | |
| 3426299 | 18 HOSE | 2 | |
| 3428060 | 19 ELBOW | 1 | |
| 3518586 | 20 BRACKET | 1 | |
| 4515426 | 21 TUBE AS | 1 | |
| 3653306 | 22 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 2136754 | BOSS | 1 | |
| 1503026 | 23 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V4292 | ELBOW | 1 | |
| 1549024 | 24 VALVE-SAMPLING (ENGINE COOLANT) | 1 | |
| 2094579 | 25 CLAMP | 7 | |
| 2735156 | 26 ADAPTER | 1 | |
| 2M9780 | 27 SEAL-O-RING | 1 | |
| 5P1076 | 28 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P7468 | 29 CLIP (SLOT) | 1 | |
| 5P7469 | 30 CLIP (TAB) | 1 | |
| 6V0545 | 31 GROMMET | 1 | |
| 6V1867 | 32 CLIP (SLOT) | 4 | |
| 6V1868 | 33 CLIP (TAB) | 4 | |
| 6V5039 | 34 CLIP (SLOT) | 3 | |
| 6V5040 | 35 CLIP (TAB) | 3 | |
| 8T1889 | 36 CLIP (SLOT) | 1 | |
| 8T1890 | 37 CLIP (TAB) | 1 | |
| 8T4121 | 38 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 39 NUT (M10X1.5-THD) | 1 | |
| 8T4183 | 40 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4196 | 41 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4223 | 42 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4244 | 43 NUT (M12X1.75-THD) | 2 | |
| 8T4835 | 44 BOLT (1/2-13X2-IN) | 2 | |
| 8T4956 | 45 BOLT (M12X1.75X35-MM) | 3 |
